Complement to HB Pushbuttons
TYPICAL INDICATOR ORDERING EXAMPLE
HB Indicators
CB
HB
SHAPES
01
Square
02
Round
01
K
HOUSING
K
Black
W01
TERMINALS
5C
W01
Silver Solder Lug
DESCRIPTION FOR TYPICAL ORDERING EXAMPLE
LEDS
Bright
5C
Red
Amber
Green
5D
5F
CAP TYPES & COLORS
LED Cap: Lens/Diffuser Color
CB
DB
FB
JB
Red/White
Amber/White
Green/White
Clear/White
HB01KW01-5C-CB
Square Shape
Red Lens and
White Diffuser
with Red, Bright LED
Black Housing
Silver Solder Lug
Terminals
Super Bright
6B
6F
6G
White
Green
Blue
LED Cap: Lens/Diffuser Color
JB
Clear/White
LED COLORS & SPECIFICATIONS
The electrical specifications shown are determined at a basic temperature of 25°C.
LED circuit is isolated and requires external power source. Single element LED is colored in OFF state.
If the source voltage exceeds the rated voltage, a ballast resistor is required.
The resistor value can be calculated by using the formula in the Supplement section.
Bright
AT633
Super Bright
AT624G
Blue
AT629B
White
AT630F
Green
T-1 Bi-pin
Note for Super Bright:
(+)
(-)
Electrostatic
Sensitive Devices
Attention
Bright
Super Bright
5C
Red
30
20
1.85
5
0.40
5D
Amber
30
20
2.0
5
0.42
–25° ~ +50°C
5F
Green
25
20
2.2
5
0.38
6B
White
30
20
3.6
5
0.50
6F
Green
30
20
3.5
5
0.50
6G
Blue
30
20
3.6
5
0.50
Unit
mA
mA
V
V
mA/°C
Color
I
FM
I
F
V
F
V
RM
∆I
F
Forward Peak Current
Continuous Forward Current
Forward Voltage
Reverse Peak Voltage
Current Reduction Rate Above 25°C
Ambient Temperature Range
–25° ~ +50°C
03-07
NKK Switches • email: sales@nkkswitches.com • Phone (480) 991-0942 • Fax (480) 998-1435 • www.nkkswitches.com
Complement to HB Pushbuttons
CAP TYPES & COLORS
Colored Cap for Bright LEDs
Lens/Diffuser
Colors Available:
AT4168
Square
(7.4) Sq
.291
(4.5)
.177
(4.8)
.189
(4.8)
.189
HB Indicators
AT4169
Round
(7.4) Dia
.291
(4.5)
.177
Transparent Colored
Lens
Translucent
White Diffuser
Colored LED
AT633
CB
DB
FB
Red/White
Amber/White
Green/White
Material: Polycarbonate
Finish: Glossy
White Cap for Bright & Super Bright LEDs
JB
Clear Lens/
White Diffuser
AT4033
Square
AT4034
Round
(7.4) Sq
.291
(4.5)
.177
(4.8)
.189
(4.8)
.189
(7.4) Dia
.291
(4.5)
.177
Transparent Clear
Lens
Translucent
White Diffuser
Colored LEDs
AT624, AT629,
AT630, or AT633
Material: Polycarbonate
Finish: Glossy
TYPICAL INDICATOR DIMENSIONS
Square
M8P0.75
(1.0) x (2.0)
.039 x .079
(1.8)
.071
L(+)
L(-)
(7.4) Sq
.291
(9.0) Sq
.354
(3.5)
.138
(5.0)
.197
(10.0)
.394
(5.3)
(15.5)
.209
.610
(0.5)
.020
(5.0)
.197
(5.08)
.200
(0.3) Typ
.012
(8.0) Dia
.315
Recommended Panel
Thickness: .020” ~ .197”
(0.5 ~ 5.0mm)
HB01KW01-5C-CB
Round
M8P0.75
(1.0) x (2.0)
.039 x .079
(1.8)
.071
L(+)
L(-)
(7.4) Dia
.291
(9.0) Dia
.354
(3.5)
.138
(5.0)
.197
(10.0)
.394
(5.3)
(15.5)
.209
.610
(0.5)
.020
(5.0)
.197
(5.08)
.200
(0.3) Typ
.012
(8.0) Dia
.315
Recommended Panel
Thickness: .020” ~ .197”
(0.5 ~ 5.0mm)
HB02KW01-5C-CB
NKK Switches • email: sales@nkkswitches.com • Phone (480) 991-0942 • Fax (480) 998-1435 • www.nkkswitches.com
03-07
