LF200ED
Series
Low Cost, 2W SMT
Dual Output
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
2W Output Power
•
Ultra-Miniature SMT Case
•
1,000 VDC Isolation
•
-40ºC to +85ºC Operation
•
Dual Output
•
Low 0.24” Profile
•
>3.5 MHour MTBF
•
Industry Standard Pin-Out
•
LOWEST COST!
Input
Parameter
Input Voltage Range
Reverse Polarity Input Current
Input Filter
Capacitor
Conditions
For Vin Change of 1%
For Iout = 10% to 100%
±7
75
150
Momentary (0.5 Sec.)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
1,000
1,000
70
70
Conditions
Ambient
Min.
-40
-55
Free Air Convection
RH, Non-condensing
95
%
Typ.
+25
Max.
+85
+125
Typ.
Max.
Units
VDC
MΩ
pF
kHz
Units
ºC
ºC
Min.
Typ.
±3.0
±1.2
±15
150
250
±0.03
Max.
Units
%
%
%
mV P - P
mV P - P
%/ºC
Conditions
5 VDC Input
12 VDC Input
Min.
4.5
10.8
Typ.
5.0
12.0
Max.
5.5
13.2
1.0
Units
VDC
A
Output
Parameter
Output Voltage Accuracy
Line Regulation
Load Regulation
Output Ripple (20 MHz)
Output Noise (20 MHz)
Temperature Coefficient
Output Short Circuit
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Case Size
Case Material
Weight
Conditions
MIL HDBK 217F, 25ºC, Gnd Benign
Conditions
5 VDC Input
12 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
3.5
Min.
-0.7
-0.7
Typ.
Max.
7.0
15.0
260.0
450
Typ.
MicroPower Direct
Physical
292 Page Street
Suite D
Stoughton, MA 02072
USA
0.70 x 0.72 x 0.24 Inches (17.78 x 18.03 x 6.0 mm)
Non-Conductive Black Plastic (UL94-V0)
0.05 Oz (1.5g)
Max.
Units
MHours
Units
VDC
ºC
mW
T:
(781) 344-8226
Reliability Specifications
F:
(781) 344-8481
Parameter
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Internal Power Dissipation
Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
Model Selection Guide
Input
Model
Number
LF201ED
LF202ED
LF203ED
LF211ED
LF212ED
LF213ED
LF214ED
Voltage (VDC)
Nominal
5
5
5
12
12
12
12
Range
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
Current (mA)
Full-Load
244
241
238
100
99
99
98
No-Load
30
30
30
15
15
15
15
Voltage
(VDC)
±5.0
±9.0
±12.0
±5.0
±9.0
±12.0
±15.0
Output
Current
(mA, Max)
±200.0
±111.0
±83.0
±200.0
±111.0
±83.0
±67.0
Current
(mA, Min)
±20.0
±11.0
±8.0
±20.0
±11.0
±8.0
±7.0
Efficiency
(%, Typ)
82
83
84
83
84
84
85
Fuse Rating
Slow-Blow
(mA)
500
500
500
200
200
200
200
Notes:
1. Output load regulation is specified for a load change of 10% to 100%.
2. When measuring output ripple, it is recommended that an external 0.33
µF
ceramic
capacitor be placed from each output to common.
3. During operation, care must be taken not to exceed the specified input range of the
unit or to allow the output load to drop below the specified minimum (10% of full
load). Operating the unit under either of these conditions could cause damage to the
unit.
4. These converters are specified for operation without external components. However,
in some applications the addition of input/output capacitors will enhance stability and
reduce output ripple. Recommended capacitor values are:
Vin
5 VDC
12 VDC
Input
Capacitor
4.7
µF
2.2
µF
Vout
5 VDC
9 VDC
12 VDC
15 VDC
Output
Capacitor
4.7
µF
2.2
µF
1.0
µF
0.47
µF
Derating Curve
For applications requiring very low output noise
levels, a simple LC filter should be effective.
5. It is recommended that a fuse be used on the
input of a power supply for protection. See the
Model Selection table above for the correct rating.
Pin Connections
Pin
1
2
3
5
6
7
Description
Pin
Description
-Vin
8
NC
+Vin
9
NC
NC
10
-Vout
-Vout
12
NC
Common
13
NC
+Vout
14
NC
NC = No Connection
Recommended Solder Profile
Mechanical Dimensions
Board Layout
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx =
±
0.01 (
±
0.25)
•
Pin 1 is marked by a “dot” or indentation on the unit
MicroPower Direct
www.micropowerdirect.com
•
292 Page Street Ste D Stoughton, MA 02072
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
