BZX84C…SEW Series
SILICON PLANAR ZENER DIODES
3
1
2
1. Anode 3. Cathode
Absolute Maximum Ratings (T
a
= 25
O
C)
Parameter
Power Dissipation
Operating Junction and Storage Temperature Range
Symbol
P
D
T
j
,T
S
Value
200
- 55 to + 150
Unit
mW
O
C
Electrical Characteristics
( T
a
= 25
O
C unless otherwise noted, V
F
< 0.9 V at I
F
= 10 mA)
Type
BZX84C2V4SEW
BZX84C2V7SEW
BZX84C3V0SEW
BZX84C3V3SEW
BZX84C3V6SEW
BZX84C3V9SEW
BZX84C4V3SEW
BZX84C4V7SEW
BZX84C5V1SEW
BZX84C5V6SEW
BZX84C6V2SEW
BZX84C6V8SEW
BZX84C7V5SEW
BZX84C8V2SEW
BZX84C9V1SEW
BZX84C10SEW
BZX84C11SEW
BZX84C12SEW
BZX84C13SEW
BZX84C15SEW
BZX84C16SEW
BZX84C18SEW
BZX84C20SEW
BZX84C22SEW
BZX84C24SEW
BZX84C27SEW
BZX84C30SEW
BZX84C33SEW
BZX84C36SEW
BZX84C39SEW
1)
Marking
Code
RF
RH
RJ
RK
RM
RN
RP
RR
RX
RY
RZ
XA
XB
XC
XD
XE
XF
XH
XJ
XK
XM
XN
XP
XR
XX
XY
XZ
YA
YB
YC
Zener Voltage Range
1)
V
Z
Min.(V)
2.2
2.5
2.8
3.1
3.4
3.7
4
4.4
4.8
5.2
5.8
6.4
7
7.7
8.5
9.4
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28
31
34
37
Max.(V)
2.6
2.9
3.2
3.5
3.8
4.1
4.6
5
5.4
6
6.6
7.2
7.9
8.7
9.6
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32
35
38
41
at l
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
Z
ZT
Max.(Ω)
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
70
80
80
80
90
130
Dynamic Resistance
at l
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
Z
ZK
Max.(Ω)
600
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
250
300
300
325
350
at I
ZK
mA
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
0.5
0.5
0.5
0.5
0.5
Reverse Current
I
R
Max.(µA)
50
20
20
5
5
3
3
3
2
1
3
2
1
0.7
0.5
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
at V
R
V
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
10.5
11.2
12.6
14
15.4
16.8
18.9
21
23.1
25.2
27.3
Tested with pulses tp = 20 ms.
SEMTECH ELECTRONICS LTD.
®
(Subsidiary
of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
Dated : 30/01/2008
BZX84C…SEW Series
Electrical Characteristics
( T
a
= 25
O
C unless otherwise noted, V
F
< 0.9 V at I
F
= 10 mA)
Type
BZX84C43SEW
BZX84C47SEW
BZX84C51SEW
BZX84C56SEW
BZX84C62SEW
BZX84C68SEW
BZX84C75SEW
1)
Marking
Code
YD
YE
YF
YH
YJ
YK
YM
Zener Voltage Range
1)
V
Z
Min.(V)
40
44
48
52
58
64
70
Max.(V)
46
50
54
60
66
72
79
at l
ZT
mA
2
2
2
2
2
2
2
Z
ZT
Max.(Ω)
150
170
180
200
215
240
255
Dynamic Resistance
at l
ZT
mA
2
2
2
2
2
2
2
Z
ZK
Max.(Ω)
375
375
400
425
450
475
500
at I
ZK
mA
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Reverse Current
I
R
Max.(µA)
0.1
0.1
0.1
0.1
0.1
0.1
0.1
at V
R
V
30.1
32.9
35.7
39.2
43.4
47.6
52.5
Tested with pulses tp = 20 ms.
SEMTECH ELECTRONICS LTD.
®
(Subsidiary
of Sino-Tech International Holdings Limited, a company
listed on the Hong Kong Stock Exchange, Stock Code: 724)
Dated : 30/01/2008
