KBPC35005W~KBPC3510W
HIGH CURRENT SINGLE-PHASE SILICON BRIDGE RECTIFIERS
REVERSE VOLTAGE: 50 to 1000 V
FORWARD CURRENT: 35 A
Features
•
Electrically isolated metal case for maximum
heat dissipation
•
Surge overload ratings to 500 A
•
Low power loss, high efficiency
•
Low reverse leakage current
•
Case to terminal isolation voltage 2500 V
•
UL recognized file # E-216968
KBPCW
Mechanical data
•
Metal or molded plastic with heatsink integrally
mounted in the bridge encapsulation
•
Mounting Position: Any
Dimensions in inches and (mm)
Absolute Maximum Ratings and Characteristics
Rating at 25
O
C ambient temperature unless otherwise specified. Single phase, half wave, 60 Hz, resistive or
inductive load. For capacitive load, derate current by 20%.
Parameter
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified
Current at T
C
= 55
O
C
Peak Forward Surge Current, 8.3 ms Single Half-Sine
-Wave superimposed on rated load (JEDEC Method)
Maximum Forward Voltage at 17.5 A DC and 25
O
C
Maximum Reverse Current at T
A
= 25
O
C
at Rated DC Blocking Voltage T
A
= 125
O
C
Typical Junction Capacitance
1)
Typical Thermal Resistance
2)
Operating and Storage Temperature Range
1)
2)
Symbols
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
C
J
R
θJC
T
J
,T
S
KBPC KBPC KBPC KBPC KBPC KBPC KBPC
Units
35005W 3501W 3502W 3504W 3506W 3508W 3510W
50
35
50
100
70
100
200
140
200
400
280
400
35
600
420
600
800
560
800
1000
700
1000
V
V
V
A
400
1.2
10
1000
300
1.4
-55 to +150
O
A
V
µA
pF
C/W
O
C
Measured at 1 MHz and applied reverse voltage of 4 VDC.
Thermal resistance from junction to case per leg.
