• 1N746A-1 THRU 1N759-1 AVAILABLE IN
JAN, JANTX
AND
JANTXV
PER MIL-PRF-19500/127
• 1N4370A-1 THRU 1N4372A-1 AVAILABLE IN
JAN, JANTX
AND
JANTXV
PER MIL-PRF-19500/127
• DOUBLE PLUG CONSTRUCTION
• METALLURGICALLY BONDED
1N746
thru
1N759A
and
1N746A-1
thru
1N759A-1
and
1N4370
thru
1N4372A
and
1N4370A-1
thru
1N4372A-1
MAXIMUM RATINGS
Operating Temperature: -65°C to +175°C
Storage Temperature: -65°C to +175°C
DC Power Dissipation: 500 mW @ +50°C
Power Derating: 4 mW / °C above +50°C
Forward Voltage @ 200mA: 1.1 volts maximum
ELECTRICAL CHARACTERISTICS @ 25°C
JEDEC
TYPE
NUMBER
(NOTE 1)
NOMINAL
ZENER
VOLTAGE
VZ @ 1ZT
(NOTE 2)
VOLTS
1N4370A
1N4371A
1N4372A
1N746A
1N747A
1N748A
1N749A
1N750A
1N751A
1N752A
1N753A
1N754A
1N755A
1N756A
1N757A
1N758A
1N759A
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10.0
12.0
mA
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
ZENER
TEST
CURRENT
1ZT
MAXIMUM
ZENER
IMPEDANCE
(NOTE 3)
ZZT@ 1ZT
OHMS
30
30
29
28
24
23
22
19
17
11
7
5
6
8
10
17
30
µ
A
MAXIMUM
REVERSE CURRENT
IR@ VR
MAXIMUM
ZENER
CURRENT
1
ZM
VOLTS
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.0
2.5
3.5
4.0
5.0
6.0
7.0
8.0
9.0
mA
155
140
125
120
110
100
90
85
75
70
65
60
55
50
45
40
35
100
60
30
5
3
2
2
5
5
5
5
2
2
1
1
1
1
FIGURE 1
DESIGN DATA
CASE:
Hermetically sealed glass
case. DO – 35 outline.
LEAD MATERIAL:
Copper clad steel.
LEAD FINISH:
Tin / Lead
THERMAL RESISTANCE: (R
OJEC):
250 ˚C/W maximum at L = .375 inch
THERMAL IMPEDANCE: (Z
OJX): 35
˚C/W maximum
NOTE 1
NOTE 2
NOTE 3
Zener voltage tolerance on "A" suffix is +5%. No Suffix denotes + 10% tolerance,
"C" suffix denotes + 2% tollerance and "D" suffix denotes + 1% tolerance.
Zener voltage is measured with the device junction in thermal equilibrium at an ambient
temperature of 25°C + 3°C.
Zener impedance is derived by superimposing on 1ZT A 60Hz rms a.c. current equal
to 10% of 1ZT
POLARITY:
Diode to be operated with
the banded (cathode) end positive.
MOUNTING POSITION:
Any.
22 COREY STREET, MELROSE, MASSACHUSETTS 02176
PHONE (781) 665-1071
FAX (781) 665-7379
WEBSITE: http://www.cdi-diodes.com
E-mail: mail@cdi-diodes.com
