70 MHz Bandpass SAW Filter
70 MHz Bandpass SAW Filter
25.9 MHz Bandwidth
Specifications
Parameter
Center Frequency at 25°C
Insertion Loss at fc
1dB Bandwidth
3dB Bandwidth
40dB Bandwidth
Passband Variation
Ultimate Rejection
Absolute Delay
Substrate Material
Ambient Temperature
Operating Temperature Range
Sym
fc
IL
BW
1
BW
3
BW
40
-
-
-
-
Ta
To
Minimum
69.95
-
25.5
25.9
-
-
45
-
-
-
-55
Typical
70
23.8
25.73
26.1
27.44
0.8
50
2.3
128-LiNbO
3
25
25
Maximum
70.05
25.0
-
-
28.0
1.2
-
-
-
-
85
Unit
MHz
dB
MHz
MHz
MHz
dB
dB
µsec
-
°C
°C
BP60510
Typical Performance
-30
-40
-50
-60
-70
-80
-90
-100
40
50
60
70
80
90
100
110
Package Outline
Matching Configuration
L1 : 180 nH
L2 : 340 nH
L3 : 680 nH
Nominal Source/Load Impedance : 50
Ω
