POWER INDUCTORS - SURFACE MOUNT
SMP8527
SMP8527LF
*
PART
NUMBER
SMP8527-101K
SMP8527-121K
SMP8527-151K
SMP8527-181K
SMP8527-221K
SMP8527-271K
SMP8527-331K
SMP8527-391K
SMP8527-471K
SMP8527-561K
SMP8527-681K
SMP8527-821K
SMP8527-102K
SMP8527-122K
SMP8527-152K
SMP8527-182K
SMP8527-222K
SMP8527-272K
SMP8527-332K
SMP8527-392K
SMP8527-472K
SMP8527-562K
SMP8527-682K
SMP8527-822K
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, Molded
L µH
@1 kHz
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
DCR
OHMS
MAX
0.011
0.012
0.013
0.014
0.016
0.017
0.018
0.020
0.024
0.026
0.034
0.037
0.043
0.048
0.049
0.054
0.059
0.070
0.077
0.084
0.101
0.113
0.145
0.173
FERRITE CORE
SATURATION CURRENT
A DC
10.0
8.4
8.2
6.8
6.4
5.8
5.4
4.8
4.2
3.8
3.4
3.2
3.0
2.8
2.6
2.2
2.0
1.8
1.8
1.6
1.4
1.4
1.2
1.2
CURRENT RATING
A DC
6.68
6.40
6.15
5.92
5.54
5.37
5.22
4.95
4.52
4.35
3.80
3.64
3.38
3.20
3.17
3.02
2.88
2.65
2.53
2.42
2.20
2.08
1.84
1.68
continued next page
Suffix “K” for 10% tolerance
Custom designs are available to meet your specific requirements; please contact factory.
*Add “LF” suffix for RoHS requirement. Example: SMP8527-101KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
0.850/0.880
(21.59/22.35)
OVER TERMINAL
MARKING: GOWANDA
P8527-XXXK
0.270/0.290
(6.86/7.37)
OVER
TERMINAL
RECOMMENDED FOOT PRINT
0.150 (3.81)
0.170
(4.32)
0.150 (3.81)
REF
0.260/0.280
(6.60/7.11)
0.780 (19.81)
CENTERS
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C temperature
rise at an ambient temperature of 85°C
• Saturation Current is the approximate value
that will reduce the initial inductance by 5%
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
480
16 mm
44 mm
13 in.
0.060/0.080 (1.52/2.03) WIDE X
0.050 (1.27) MIN DEEP
2 SIDES
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
122813
POWER INDUCTORS - SURFACE MOUNT
continued from previous page
SMP8527
SMP8527LF
*
PART
NUMBER
SMP8527-103K
SMP8527-123K
SMP8527-153K
SMP8527-183K
SMP8527-223K
SMP8527-273K
SMP8527-333K
SMP8527-393K
SMP8527-473K
SMP8527-563K
SMP8527-683K
SMP8527-823K
SMP8527-104K
SMP8527-124K
SMP8527-154K
SMP8527-184K
SMP8527-224K
SMP8527-274K
SMP8527-334K
SMP8527-394K
SMP8527-474K
SMP8527-564K
SMP8527-684K
SMP8527-824K
SMP8527-105K
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, Molded
L µH
@1 kHz
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
DCR
OHMS
MAX
FERRITE CORE
0.208
0.283
0.414
0.468
0.505
0.620
0.720
0.770
1.00
1.27
1.50
1.96
2.28
2.52
3.49
3.89
4.40
5.78
7.51
8.44
9.56
13.20
15.00
17.00
22.80
SATURATION CURRENT
A DC
1.00
0.960
0.860
0.800
0.680
0.620
0.600
0.540
0.500
0.500
0.450
0.420
0.360
0.320
0.280
0.260
0.240
0.200
0.180
0.170
0.150
0.140
0.130
0.120
0.100
CURRENT RATING
A DC
1.54
1.32
1.10
1.02
0.990
0.890
0.826
0.799
0.700
0.620
0.570
0.500
0.460
0.440
0.380
0.360
0.330
0.290
0.260
0.240
0.230
0.190
0.180
0.170
0.150
Suffix “M” for 20% tolerance and Suffix “K” for 10% tolerance
Custom designs are available to meet your specific requirements; please contact factory.
*Add “LF” suffix for RoHS requirement. Example: SMP8527-101KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
0.850/0.880
(21.59/22.35)
OVER TERMINAL
MARKING: GOWANDA
P8527-XXXK
0.270/0.290
(6.86/7.37)
OVER
TERMINAL
RECOMMENDED FOOT PRINT
0.150 (3.81)
0.170
(4.32)
0.150 (3.81)
REF
0.260/0.280
(6.60/7.11)
0.780 (19.81)
CENTERS
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C temperature
rise at an ambient temperature of 85°C
• Saturation Current is the approximate value
that will reduce the initial inductance by 5%
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
480
16 mm
44 mm
13 in.
0.060/0.080 (1.52/2.03) WIDE X
0.050 (1.27) MIN DEEP
2 SIDES
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
122813
