KR Electronics, Inc.

KR Electronics

General Description

KR 2725 is a 9 MHz bandpass filter with a minimum 3 dB

bandwidth of 900 KHz. Other center frequencies and band-

widths available. Please consult the factory.

www.krfilters.com

Features

•

9 MHz Center Frequency

•

3 dB Bandwidth, 900 KHz min

•

SMA connectors

•

50

Ω

Source and Load

Typical Performance

Passband Amplitude

(1 dB/div)

17 Oct 2006 15:28:56

CH1

S 21

log MAG

1 dB/

REF 0 dB

CH2

S 21

log MAG

Overall Response

(10 dB/div)

17 Oct 2006 15:30:46

10 dB/

REF 0 dB

PRm

Cor

PRm

Avg

16

CH1 CENTER

9.000 000 MHz

SPAN

.900 000 MHz

CH2 START

1.000 000 MHz

STOP 100.000 000 MHz

KR Electronics, Inc.

91 Avenel Street

Avenel, NJ 07001

Web

Email

Phone

Fax

www.krfilters.com

sales@krfilters.com

(732) 636-1900

(732) 636-1982

Page 1
