Sunlight Visible. Low Current. Single- and Multi-Color.
1.8x5mm 10-LED Linear Bargraphs
Features
Applications
Options
•
5-10-15 Single Color,
•
•
•
•
Sunlight Visible LEDs in a
Linear Arrangement
Uniform LED Appearance
Solid-State, High Shock/
Vibration Resistant
Segment Size: 1.8 x 5mm
LED Operating Life:
100,000+ hrs (10+ Years)
•
New LED Chip
Technology: InGaAIP,
GaN
•
Fast Turn On/Off Time
•
High On/Off Contrast
•
Linear Bargraphs are
Dip-Socket Compatible
•
Avionics Instrumentation
•
Process Control Gauges
•
Audio/Video Level
•
•
Indicators
Temperature Indicators
Speedometer
•
Colors: Orange, Lime Green, Blue
•
Low Current (2mA) LEDs
•
Surface Mount LEDs
•
Multi-Color, Sunlight Visible LEDs
•
Configurations: 5-LED, 10-LED
and 15-LED Linear Bargraphs
•
Mix LED Color Linear Bargraphs
for OEM Applications
Super Intensity, Sunlight V isible
10-LED Linear Bargraphs
.995
[25.27]
.070 TYP
[1.78]
Part Number
Color
Lens Type
Electrical-Optical
Characteristics (Ta = 25 C)
I
f (mA)
I
v (mcd) Vf (V)
typ
typ
typ/max
λ
p
(nm)
LBG1000E3KB
.20
[5.08]
.400
[10.16]
SP RED
SP YELLOW
MILKY
WHITE
20
20
20
70
70
60
2.0/2.6 633
2.0/2.6 592
3.5/4.0 523
LBG1000Y3KB
LBG1000AG3KB AQUA GREEN
Custom Mixed Color
.118
[3.0]
Pin 1
.100 TYP
[2.54]
.315
[8.0]
Part Number Example: LBG1000X3KB-RYGGGGGGYR
1) Black face bargraphs are illustrated and listed as Part Numbers.
2) Gray face bargraphs are available. When ordering gray , remove the last "B" from
the Part Number in this table's left column.
Standard Intensity
.020
[0.5]
.100 TYP
[2.54]
.012
[0.30]
.300
[7.62]
Part Number
Color
Lens Type
Electrical-Optical
Characteristics (Ta = 25 C)
I
f (mA)
I
v (mcd) Vf (V)
typ
typ
typ/max
λ
p
(nm)
LBG1000R6B
LBG1000R3B
20 19 18 17 16 15 14 13 12 11
20 19 18 17 16 15 14 13 12 11
UL RED
HE RED
YELLOW
HE GREEN
LBG1000Y3B
LBG1000G3B
MILKY
WHITE
10
10
10
10
10.5
4.5
5.0
7.5
1.7/2.5 660
1.9/2.5 635
2.0/2.5 585
2.1/2.5 565
Custom Mixed Color
Note:
Segment color is white when off
1
2
3
4
5
6
7
8
9 10
1
2
3
4
5
6
7
8
9 10
ULTRA RED
HE RED, YELLOW , HE GREEN
Part Number Example: LBG1000T3-3R4Y3G
1) Black face bargraphs are illustrated and listed as Part Numbers.
2) Gray face bargraphs are available. When ordering gray , remove the last "B" from
the Part Number in this table's left column.
Optional Configurations:
5 LED Linear
Bargraph
10 LED Linear
Bargraph
15 LED Linear
Bargraph
Custom OEM Configurations:
5 LED Linear
Bargraph with
Mix Colors
10 LED Linear
Bargraph with
Mix Colors
15 LED Linear
Bargraph with
Mix Colors
LEDTRONICS,
INC.
THE FUTURE OF LIGHT
23105 Kashiwa Court, Torrance, CA 90505
Phone: (800) 579-4875 or (310) 534-1505 Fax: (310) 534-1424
E-mail: webmaster@ledtronics.com
Website: http://www.ledtronics.com
Log # 131 Rev 5-2001
