FUJITSU SEMICONDUCTOR
DATA SHEET
DS07-12558-3E
8-bit Proprietary Microcontrollers
CMOS
F
2
MC-8L MB89210 Series
MB89215/F217/P215/PV210
s
DESCRIPTION
The MB89210 series is a one-chip microcontroller that features a compact instruction set and contains a range
of peripheral functions including timers, a serial interface, A/D converters and external interrupts.
s
FEATURES
•
•
•
•
•
•
•
•
•
•
F
2
MC-8L CPU core
Maximum memory spaces
: 64 Kbytes
Minimum instruction execution time : 0.32
µs
to 5.12
µs
(at 12.5 MHz)
Interrupt processing time
: 2.88
µs
to 46.08
µs
(at 12.5 MHz)
I/O port
: Max 22
21-bit time base timer
8-bit PWM timer
8-/16-bit capture timer/counter : 2 ch
Watchdog timer
12-bit PPG timer
(Continued)
s
PACKAGE
30-pin Plastic SSOP
48-pin Plastic QFP
48-pin Ceramic MQFP
(FPT-30P-M02)
(FPT-48P-M13)
(MQP-48C-P02)
MB89210 Series
(Continued)
• 10-bit A/D converter : 8 ch
• LIN-UART
• 8-bit serial I/O
• External Interrupt : 3 ch
• External or CR (built-in) oscillation clock, switchable
• Low power consumption modes (stop modes, sleep modes)
• Package : SSOP-30,QFP-48, MQFP-48
• CMOS technology
2
MB89210 Series
s
PRODUCT LINEUP
Part number
Parameter
Type
MB89215
For mass products
(Mask ROM
product)
16 Kbyte
(Built-in ROM)
512 byte
MB89F217
Flash products
(Flash ROM
product)
32 Kbyte
(Built-in Flash
memory)
1 Kbyte
MB89P215
One-time product
(for small-scale
production)
16 Kbyte
(Built-in PROM)
512 byte
MB89PV210
Piggy back/
Evaluation product
(for development)
32 Kbyte
(External EPROM)
2 Kbyte
ROM capacity
RAM capacity
CPU functions
Number of basic instructions
Instruction bit length
Instruction length
Data bit length
Minimum instruction execution time
Interruption processing time
: 136
: 8 bits
: 1 to 3 bytes
: 1, 8, and 16 bits
: 0.32
µs
to 5.12
µs
(at 12.5 MHz)
: 2.88
µs
to 46.08
µs
(at 12.5 MHz)
Ports
21-bit time base timer
Watchdog timer
8-bit PWM timer
Peripheral functions
General purpose I/O port
×
21 (also usable as resources) General purpose input port
×
1
21 bits
Interrupt cycle : at 10 MHz (0.82 ms,3.3 ms,26.2 ms,419.4 ms)
Reset generation cycle : at 10 MHz (Min 419.4 ms)
8-bit interval timer operation (supports square wave output, operating clock period :
0.4
µs
to 25.6
µs)
8-bit resolution PWM operation (conversion period : 102.4
µs
to 26.84
µs
)
8-bit capture timer/counter
×
1 channel
+
8-bit timer
8/16-bit capture timer or 16-bit capture timer/counter
×
1 channel
counter
Capable of event count operation and square wave output using external clock input
with 8-bit timer 0 or 16-bit counter
LIN-UART
8-bit serial I/O
12-bit PPG timer
External interrupt
circuit
Full duplex, Synchronous/asynchronous transfer (with start/stop bit), Capable of
setting over 30,000 different baud rates using a 15-bit reload counter
Support for the LIN protocol, slave nodes, and LIN synch break/sync field detection
8-bit length, Selectable LSB first or MSB first
Transfer clock (0.8
µs
external, 0.8
µs,
3.2
µs,
12.8
µs
internal)
Output requency : Selectable pulth width and cycle (Cycle : 1.6
µs
to 419.3 ms )
3-channel (interrupt vector, request flag, requesr output acceptance)
Edge selectable (selectable rising, falling or both edge)
Can be use for recovery from stop or sleep mode (edge detection also available in
stop mode).
10-bit accurasy
×
8-channel
A/D conversion function (conversion time : 15.2
µs/10
MHz)
Continuous activation by an 8-/16-bit timer/counter output or time base timer output
capable.
Sleep mode and Stop mode
3.5 V to 5.5 V
Yes
3.5 V to 5.5 V
Yes
3.5 V to 5.5 V
Yes
3.5 V to 5.5 V
No
A/D converter
Standby mode
Operating voltage *
CR(built-in) oscillator
* : The minimum operating voltage varies with the operating frequency, the function and the connected ICE.
Note : Unless otherwise stated, clock periods and conversion times are for 10 MHz operation with the internal clock
operating at maximum speed.
3
MB89210 Series
s
PACKAGES AND CORRESPONDING PRODUCTS
Package
FPT-30P-M02
FPT-48P-M13
MQP-48C-P02
Power supply pins
O : Yes
×
: No
MB89215
O
O
MB89F217
MB89P215
O
MB89PV210
×
O
×
×
Vcc,Vss
×
2
×
*
1
×
*
2
O
Vcc, Vss
×
2,
AVcc, AVss
×
Vcc,Vss
×
2
×
Vcc, Vss
×
3,
AVcc, AVss
*1 : Adapter for 48-pin to 30-pin conversion (manufactured by Sunhayato Corp.)
Part number : 48QF-30SOP-8L
Inquiry : Sunhayato Corp.
TEL
: (81)-3-3984-7791
FAX
: (81)-3-3971-0535
E-mail : adapter@sunhayato.co.jp
*2 : Adapter for 48-pin (EVA) to 48-pin (MASK/FLASH) conversion.
Part number : 48QF2-48QF2-8L-FJ
Inquiry : Sunhayato Corp.
TEL
: (81)-3-3984-7791
FAX
: (81)-3-3971-0535
E-mail : adapter@sunhayato.co.jp
s
DIFFERENCES AMONG PRODUCTS
1. Memory space
When this product is used in a piggy-back or other evaluation configuration, it is necessary to carefully confirm
the differences between the model being used and the product it is evaluating.
2. Current Consumption
• On the MB89PV210, the additional current consumed by the EPROM is added at the connecting socket on
the back side.
• When operating at low speed, the current consumption in the one-time PROM or EPROM models is greater
than on the mask ROM models. However, current consumption in sleep or stop modes is identical. However,
in sleep/stop mode the current consumption is the same.
4
