ZPD1 thru ZPD75
Vishay Semiconductors
formerly General Semiconductor
Zener Diodes
V
Z
Range
1.0, 2.7 to 75V
Power Dissipation
500mW
DO-204AH (DO-35 Glass)
Features
• Silicon Planar Zener Diodes.
• The Zener voltages are graded according to the
international E 12 standard. Offered with either 5%
or 2% tolerance. Smaller voltage tolerances and
other Zener voltages are available upon request.
• These diodes are also available in MiniMELF case
with the type designation ZMM1 ... ZMM75.
Mechanical Data
Case:
DO-35 Glass Case
Weight:
approx. 0.13g
Packaging codes/options:
D7/10K per 13” reel, (52mm tape), 20K/box
D8/10K per Ammo tape (52mm tape), 20K/box
Dimensions in inches and (millimeters)
Maximum Ratings and Thermal Characteristics
Parameter
Zener Current (see Table “Characteristics”)
Power Dissipation at T
amb
= 25°C
Thermal Resistance Junction to Ambient Air
Junction Temperature
Storage Temperature Range
P
tot
R
θJA
T
j
T
S
Symbol
(T
A
= 25°C unless otherwise noted)
Value
500
(1)
300
(2)
175
–55 to +175
Unit
mW
°C/W
°C
°C
Notes:
(1) Valid provided that leads at a distance of 8mm from case are kept at ambient temperature
(2) Valid provided that leads at a distance of 4mm from case are kept at ambient temperature
Document Number 88415
02-May-02
www.vishay.com
1
ZPD1 thru ZPD75
Vishay Semiconductors
formerly General Semiconductor
Electrical Characteristics
Type
add suffix SB14686
for 2% tol.
ZPD1
(3)
ZPD2.7
ZPD3
ZPD3.3
ZPD3.6
ZPD3.9
ZPD4.3
ZPD4.7
ZPD5.1
ZPD5.6
ZPD6.2
ZPD6.8
ZPD7.5
ZPD8.2
ZPD9.1
ZPD10
ZPD11
ZPD12
ZPD13
ZPD15
ZPD16
ZPD18
ZPD20
ZPD22
ZPD24
ZPD27
ZPD30
ZPD33
ZPD36
ZPD39
ZPD43
ZPD47
ZPD51
ZPD56
ZPD62
ZPD68
ZPD75
(T
A
= 25°C unless otherwise noted)
Dynamic Resistance
at I
Z
= 1 mA
at I
Z
= 5 mA
f = 1 kHz
f = 1 kHz
r
zj
(Ω)
r
zj
(Ω)
6.5 (< 8)
75 (< 83)
80 (< 95)
80 (< 95)
80 (< 95)
80 (< 95)
80 (< 95)
70 (< 78)
30 (< 60)
10 (< 40)
4.8 (< 10)
4.5 (< 8)
4 (< 7)
4.5 (< 7)
4.8 (< 10)
5.2 (< 15)
6 (< 20)
7 (< 20)
9 (< 25)
11 (< 30)
13 (< 40)
18 (< 50)
20 (< 50)
25 (< 55)
28 (< 80)
30 (< 80)
35 (< 80)
40 (< 80)
40 (< 90)
50 (< 90)
60 (< 100)
70 (< 100)
70 (< 100)
< 135
(4)
Temperature Coefficient
of Zener Voltage at I
Z
= 5 mA
α
vz
(10
–4
/°C)
min
max
–26
–9
–9
–8
–8
–7
–6
–5
–3
–2
–1
+2
+3
+4
+5
+5
+5
+6
+7
+7
+8
+8
+8
+8
+8
+8
+8
+8
+8
+10
+10
+10
+10
–23
–4
–3
–3
–3
–3
–1
+2
+4
+6
+7
+7
+7
+7
+8
+8
+9
+9
+9
+9
+9.5
+9.5
+10
+10
+10
+10
+10
+10
+10
+12
+12
+12
+12
typ. +10
(4)
Reverse
Voltage
at I
R
= 100 nA
V
R
(V)
–
–
–
–
–
–
–
–
> 0.8
>1
>2
>3
>5
>6
>7
> 7.5
> 8.5
>9
> 10
> 11
> 12
> 14
> 15
> 17
> 18
> 20
> 22.5
> 25
> 27
> 29
> 32
> 35
> 38
> 42
> 47
> 51
> 55
Admissible Zener current
(2)
at
at
T
amb
= 25°C
T
amb
= 45°C
I
Z
(mA)
I
Z
(mA)
280
135
117
109
101
92
85
76
67
59
54
49
44
40
36
33
30
28
25
23
20
18
17
16
13
12
10
9
9
8
7
6
6
5.2
4.8
4.1
3.9
340
160
140
130
120
110
100
90
80
70
64
58
53
47
43
40
36
32
29
27
24
21
20
18
16
14
13
12
11
10
9.2
8.5
7.8
7.1
6.4
5.8
5.3
< 50
< 500
< 500
< 500
< 500
< 500
< 500
< 500
< 480
< 400
< 200
< 150
< 50
< 50
< 50
< 70
< 70
< 90
< 110
< 110
< 170
< 170
< 220
< 220
< 220
< 250
< 250
< 250
< 250
< 300
< 700
< 750
< 750
< 1000
(5)
< 150
(4)
< 200
(4)
< 250
(4)
< 1000
(5)
< 1000
(5)
< 1500
(5)
typ. +10
(4)
typ. +10
(4)
typ. +10
(4)
Notes:
(1) Tested with pulses t
p
= 5ms
(2) Valid provided that leads at a distance of 4 mm from case are kept at ambient temperature
(3) The ZPD1 is a silicon diode operated in forward direction. Hence, the subscript of all parameters should be “F” instead of “Z”.
Connect the cathode terminal to the negative pole
(4) at I
Z
= 2.5mA
(5) at I
Z
= 0.5mA
www.vishay.com
2
Document Number 88415
02-May-02
ZPD1 thru ZPD75
Vishay Semiconductors
formerly General Semiconductor
Electrical Characteristics
Type
± 5% Tol.
ZPD1
(3)
ZPD2.7
ZPD3
ZPD3.3
ZPD3.6
ZPD3.9
ZPD4.3
ZPD4.7
ZPD5.1
ZPD5.6
ZPD6.2
ZPD6.8
ZPD7.5
ZPD8.2
ZPD9.1
ZPD10
ZPD11
ZPD12
ZPD13
ZPD15
ZPD16
ZPD18
ZPD20
ZPD22
ZPD24
ZPD27
ZPD30
ZPD33
ZPD36
ZPD39
ZPD43
ZPD47
ZPD51
ZPD56
ZPD62
ZPD68
ZPD75
Zener Voltage
range
(1)
at I
Z
V
Z
(V)
min.
max.
0.70
2.50
2.80
3.10
3.40
3.70
4.00
4.40
4.80
5.20
5.80
6.40
7.00
7.70
8.50
9.40
10.4
11.4
12.4
13.8
15.3
16.8
18.8
20.8
22.8
25.1
28.0
31.0
34.0
37.0
40.0
44.0
48.0
52.0
58.0
64.0
70.0
0.80
2.90
3.20
3.50
3.80
4.10
4.60
5.00
5.40
6.00
6.60
7.20
7.90
8.70
9.60
10.6
11.6
12.7
14.1
15.6
17.1
19.1
21.2
23.3
25.6
28.9
32.0
35.0
38.0
41.0
46.0
50.0
54.0
60.0
66.0
72.0
79.0
(T
A
= 25°C unless otherwise noted)
Test Current
I
Z
(mA)
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
2.5
2.5
2.5
2.5
Type
add suffix SB14686
for ± 2% Tol.
ZPD1
(3)
ZPD2.7
ZPD3
ZPD3.3
ZPD3.6
ZPD3.9
ZPD4.3
ZPD4.7
ZPD5.1
ZPD5.6
ZPD6.2
ZPD6.8
ZPD7.5
ZPD8.2
ZPD9.1
ZPD10
ZPD11
ZPD12
ZPD13
ZPD15
ZPD16
ZPD18
ZPD20
ZPD22
ZPD24
ZPD27
ZPD30
ZPD33
ZPD36
ZPD39
ZPD43
ZPD47
ZPD51
ZPD56
ZPD62
ZPD68
ZPD75
Zener Voltage
range
(1)
at I
Z
V
Z
(V)
min.
max.
-
2.65
2.94
3.23
3.53
3.82
4.21
4.61
5.00
5.49
6.08
6.66
7.35
8.04
8.92
9.80
10.8
11.8
12.7
14.7
15.7
17.6
19.6
21.6
23.5
26.5
29.4
32.3
35.3
38.2
42.1
46.1
50.0
54.9
60.8
66.6
73.5
-
2.75
3.06
3.37
3.67
3.98
4.39
4.79
5.20
5.71
6.32
6.94
7.65
8.36
9.28
10.2
11.2
12.2
13.3
15.3
16.3
18.4
20.4
22.4
24.5
27.5
30.6
33.7
36.7
39.8
43.9
47.9
52.0
46.9
63.2
69.4
76.5
Test Current
I
Z
(mA)
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
2.5
2.5
2.5
2.5
Notes:
(1) Measured with pulses t
p
= 5 ms
(3) The ZPD1 is a silicon diode operated in forward direction. Hence, the
subscript of all parameters should be “F” instead of “Z”.
Connect the cathode terminal to the negative pole
Document Number 88415
02-May-02
www.vishay.com
3
