F-210 SUPPLEMENT
HPSTP–19–1000–ML–ML
TM
HPSTP SERIES
HPSTP–19–2000–S–S
HI-SPEED SHIELDED TWISTED PAIR CABLE
SPECIFICATIONS
For complete specifications see
www.samtec.com?HPSTP
Signal Routing:
100Ω Differential
Pinout Map:
See web address above
RoHS Compliant:
Yes
HPSTP
Cable Length
1 meter (39.4")
30 AWG Shielded Twised Pair
1.78 GHz / 3.56 Gbps
Mates with:
HDMI, MHDMI
30 AWG Shielded
Twisted Pair cable
Higher bandwidth in industry
standard HDMI™ form factor
Performance data for other cable lengths and complete
test data available at www.samtec.com?HPSTP or
contact sig@samtec.com
Outer
EMI
Shield
19 or 29
Positions
ALSO
AVAILABLE
• 30 AWG twinax cable.
(See HPDPI Series)
• Custom cable lengths/
higher performance.
• Standard HDMI
™
cables.
Call Samtec.
TYPE
NO. OF
POSITIONS
LENGTH
END
NO. 1
END
NO. 2
–19
HPSTP
= Micro Shielded
Twisted Pair Cable
= 5 Pairs, 5 Power,
19 Positions
–“XXXX”
= Length in
millimeters
–1000, –2000,
–3000, –5000
–S
–S
= Standard HDMI
= Standard HDMI
(–S–S & –M–S only)
–29
= 8 Pairs, 5 Power,
29 Positions
(–S end
option only)
–M
= Mini HDMI
(19 positions only)
(–5000 length not available)
–M
= Mini HDMI
(–M–M & –S–M only.
19 positions only.)
(–5000 length not
available)
–SL
NO. OF
POSITIONS
–19
–29
A
(13,90)
.547
(21,20)
.835
B
C
NO. OF
PAIRS
05
08
= Standard HDMI with Locking
(19 positions only)
–SL
= Standard HDMI
with Locking
(–SL–SL only.
19 positions only.)
(20,51) (11,10)
.807
.437
(27,20) (13,00)
1.071 .512
–ML
= Mini HDMI with Latching
(19 positions only)
(–5000 length not available)
(6,50)
.256
–ML
= Mini HDMI
with Latching
(–ML–ML only.
19 positions only.)
(–5000 length not
available)
OVERALL LENGTH (XXXX) ± 2%
(30,84) 1.214
A
B
(18,00)
.709
HDMI
™
is a trademark of
HDMI Licensing LLC.
Note:
This product is non-standard,
non-returnable.
C
(4,45)
.175
(10,00) .394
(2,42)
.095
