IDT74ALVCH16540PA datasheet, PDF

Datasheet> All Categories > logic> logic> IDT74ALVCH16540PA

IDT74ALVCH16540PA: DescriptionBus Driver, ALVC/VCX/A Series, 2-Func, 8-Bit, Inverted Output, CMOS, PDSO48, TSSOP-48; Categorylogic logic; File Size103KB，6 Pages; ManufacturerIDT (Integrated Device Technology)

Download Datasheet Parametric Compare View All

IDT74ALVCH16540PA Overview

Bus Driver, ALVC/VCX/A Series, 2-Func, 8-Bit, Inverted Output, CMOS, PDSO48, TSSOP-48

IDT74ALVCH16540PA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	TSSOP
package instruction	TSSOP, TSSOP48,.3,20
Contacts	48
Reach Compliance Code	not_compliant
Other features	WITH DUAL OUTPUT ENABLE
Control type	ENABLE LOW
series	ALVC/VCX/A
JESD-30 code	R-PDSO-G48
JESD-609 code	e0
length	12.5 mm
Logic integrated circuit type	BUS DRIVER
MaximumI(ol)	0.024 A
Humidity sensitivity level	1
Number of digits	8
Number of functions	2
Number of ports	2
Number of terminals	48
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output characteristics	3-STATE
Output polarity	INVERTED
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Encapsulate equivalent code	TSSOP48,.3,20
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
power supply	3.3 V
Prop。Delay @ Nom-Sup	3 ns
propagation delay (tpd)	3.6 ns
Certification status	Not Qualified
Maximum seat height	1.2 mm
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	2.7 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn85Pb15)
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	DUAL
width	6.1 mm
Base Number Matches	1

Preview

Download Datasheet

View All

IDT74ALVCH16540

3.3V CMOS 16-BIT INVERTING BUFFER/LINE DRIVER

EXTENDED COMMERCIAL TEMPERATURE RANGE

3.3V CMOS 16-BIT INVERTING

BUFFER/LINE DRIVER

WITH 3-STATE OUTPUTS

AND BUS-HOLD

FEATURES:

0.5 MICRON CMOS Technology

Typical t

SK(0)

(Output Skew) < 250ps

ESD > 2000V per MIL-STD-883, Method 3015;

> 200V using machine model (C = 200pF, R = 0)

– 0.635mm pitch SSOP, 0.50mm pitch TSSOP,

and 0.40mm pitch TVSOP packages

– Extended commercial range of – 40°C to + 85°C

– V

= 3.3V ± 0.3V, Normal Range

– V

= 2.7V to 3.6V, Extended Range

– V

= 2.5V ± 0.2V

– CMOS power levels (0.4µ W typ. static)

– Rail-to-Rail output swing for increased noise margin

Drive Features for ALVCH16540:

– High Output Drivers: ±24mA

– Suitable for heavy loads

–

IDT74ALVCH16540

DESCRIPTION:

This 16-bit inverting buffer/line driver is built using advanced dual

metal CMOS technology. The ALVCH16540 offers bus/backplane

interface capability with improved packing density and a flow-through

organization for simplifying board layout. It is designed specifically to

improve the performance and density of 3-state memory address

drivers, clock drivers, and bus-oriented receivers and transmitters. The

three-state controls operate this device in a quad-nibble, dual-byte, or

single 16-bit word mode. The 3-state outputs are controlled by the output

enable (OE) pins. A high on OE causes the outputs to force a high

impedance off-state. All inputs are designed with hysteresis for improved

noise margin.

The ALVCH16540 has been designed with a ±24mA output driver.

This driver is capable of driving a moderate to heavy load while

maintaining speed performance.

The ALVCH16540 has “bus-hold” which retains the inputs’ last state

whenever the input bus goes to a high impedance. This prevents floating

inputs and eliminates the need for pull-up/down resistors.

APPLICATIONS:

•

3.3V High Speed Systems

•

3.3V and lower voltage computing systems

FUNCTIONAL BLOCK DIAGRAM

EXTENDED COMMERCIAL TEMPERATURE RANGE

1999 Integrated Device Technology, Inc.

OCTOBER 1999

DSC-4545/-

IDT74ALVCH16540PA Related Products

	IDT74ALVCH16540PA	IDT74ALVCH16540PV	IDT74ALVCH16540PF
Description	Bus Driver, ALVC/VCX/A Series, 2-Func, 8-Bit, Inverted Output, CMOS, PDSO48, TSSOP-48	Bus Driver, ALVC/VCX/A Series, 2-Func, 8-Bit, Inverted Output, CMOS, PDSO48, SSOP-48	Bus Driver, ALVC/VCX/A Series, 2-Func, 8-Bit, Inverted Output, CMOS, PDSO48, TVSOP-48
Is it Rohs certified?	incompatible	incompatible	incompatible
Parts packaging code	TSSOP	SSOP	SOIC
package instruction	TSSOP, TSSOP48,.3,20	SSOP, SSOP48,.4	TVSOP-48
Contacts	48	48	48
Reach Compliance Code	not_compliant	not_compliant	not_compliant
Other features	WITH DUAL OUTPUT ENABLE	WITH DUAL OUTPUT ENABLE	WITH DUAL OUTPUT ENABLE
Control type	ENABLE LOW	ENABLE LOW	ENABLE LOW
series	ALVC/VCX/A	ALVC/VCX/A	ALVC/VCX/A
JESD-30 code	R-PDSO-G48	R-PDSO-G48	R-PDSO-G48
JESD-609 code	e0	e0	e0
length	12.5 mm	15.875 mm	9.7 mm
Logic integrated circuit type	BUS DRIVER	BUS DRIVER	BUS DRIVER
MaximumI(ol)	0.024 A	0.024 A	0.024 A
Humidity sensitivity level	1	1	1
Number of digits	8	8	8
Number of functions	2	2	2
Number of ports	2	2	2
Number of terminals	48	48	48
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C
Output characteristics	3-STATE	3-STATE	3-STATE
Output polarity	INVERTED	INVERTED	INVERTED
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	TSSOP	SSOP	TSSOP
Encapsulate equivalent code	TSSOP48,.3,20	SSOP48,.4	TSSOP48,.25,16
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
power supply	3.3 V	3.3 V	3.3 V
Prop。Delay @ Nom-Sup	3 ns	3 ns	3 ns
propagation delay (tpd)	3.6 ns	3.6 ns	3.6 ns
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.2 mm	2.794 mm	1.2 mm
Maximum supply voltage (Vsup)	3.6 V	3.6 V	3.6 V
Minimum supply voltage (Vsup)	2.7 V	2.7 V	2.7 V
Nominal supply voltage (Vsup)	3.3 V	3.3 V	3.3 V
surface mount	YES	YES	YES
technology	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	Tin/Lead (Sn85Pb15)	Tin/Lead (Sn85Pb15)	Tin/Lead (Sn85Pb15)
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	0.635 mm	0.4 mm
Terminal location	DUAL	DUAL	DUAL
width	6.1 mm	7.493 mm	4.4 mm
Maker	-	IDT (Integrated Device Technology)	IDT (Integrated Device Technology)
