IMISG508APB

Description
Clock Generator, PDIP16,
CategoryThe embedded processor and controller    Microcontrollers and processors
File Size266KB,7 Pages
ManufacturerCypress Semiconductor
Download Datasheet Parametric View All

IMISG508APB Overview

Clock Generator, PDIP16,

IMISG508APB Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Reach Compliance Codecompliant
JESD-30 codeR-PDIP-T16
JESD-609 codee0
Number of terminals16
Maximum operating temperature70 °C
Minimum operating temperature
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Encapsulate equivalent codeDIP16,.3
Package shapeRECTANGULAR
Package formIN-LINE
power supply5 V
Certification statusNot Qualified
Maximum slew rate30 mA
Nominal supply voltage5 V
surface mountNO
Temperature levelCOMMERCIAL
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Base Number Matches1
IMISG508
May 1996
REDUCED EMI CLOCK CHIP
CMOS LSI
SPECTRUM SPREAD CLOCK GENERATOR
PRODUCT FEATURES
S
S
S
S
S
S
S
S
S
S
S
S
PRODUCT DESCRIPTION
The IMISG508 is a spectrum spread clock generator
specially designed for personal computers, laser
printers and other digital systems. IMISG508 uses a
patented concept to generate popular clock frequencies
that are intentionally boradbanded to reduce
electromagnetic interference. IMISG508 attenuates the
radiated emission amplitudes from products associated
with either the clock harmonics or any signals derived
from the clock signals nominally 10 dB and could
significantly reduce the cost of complying with the
regulatory requirements.
PRCLK is the broadbanded output and can be
programmed by the PRCLK Frequency Selection Table
on page 2. A single, low cost external crystal is required
as reference frequency for the synthesizer. Output
modulation function can be turned off with the SSON
pin. Several power down modes add the flexibility to
operate the device in a completely static mode to
reduce standby currents and simplify system board
tests.
Generates CPU Clock Signals for Microprocessor
Systems
Reduces Measured EMI by 10 dB nominal
4V to 6V Operating Supply Range
Supports CPUs from all major manufacturers
Wide Range of Selectable Output Frequencies
including 40, 30, 25, and 16.7 MHz.
Single, Low Cost Crystal used as Reference
Frequency
Glitch-Free Switching
50% Duty Cycle
Power Down Mode for Low Power consumption
TTL or CMOS Compatible Outputs with 6 mA Drive
Capability
Low, Short- and Long-Term Jitter
16 Pin PDIP and 16 Pin SOIC (300 mil Body)
Package Options
CONNECTION DIAGRAM
VDD
OSCin
OSCout
VSS
MPSEL
AVDD
S0
S1
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
TS
VDD
MPCLK
VSS
PRCLK
AVSS
LF1
SSON
BLOCK DIAGRAM
3
44.2
MHz
2
REF
/4 or /12
14
MPCLK
APPLICATIONS
MPSEL 5
LF 10
S0 7 SPECTRUM
SPREAD
S1 8
CLOCK GEN
TS 16
SSON
9
The IMISG508 eliminates the need for multiple
oscillators and generates the CPU clock signals for
personal computers, laser printers and other digital
systems. Supports CPUs from all major manufacturers.
IMISG508 can be used with laptop or notebook
computers to save power by running the system slower
than normal CPU speeds or completely disabling the
clocks in standby mode.
12
/2
PRCLK
INTERNATIONAL MICROCIRCUITS, INC. 525 LOS COCHES ST.
MILPITAS, CA 95035 TEL: 408-263-6300 FAX 408-263-6571
Rev. 1.0
Page 1 of 7
