90 WATTS MEDICAL POWER ADAPTERS

Preview

Download Datasheet

View All

TRUMPower

D E SCR IPTION

The TMP90 is a series of AC/DC desktop power

adapters with 60 to 90 watts of continuous output

power. They are enclosed in a 94V-1 rated case with

an IEC 320/C14 or C18 inlet for medical and ITE

applications. All models meet EN55011, EN55022 and

FCC class B emission limits, and are designed for

medical applications.

90 WATTS MEDICAL POWER ADAPTERS

TMP90 SERIES

( LV D )

RoHS

F EATU R E S

‧

Low safety ground leakage current

IEC320/C14 (Class I) or C18 (Class II) Inlet

9 0 t o 2 6 4 VA C w i d e i n p u t r a n g e

Optional output connectors

O v e r v o l ta g e & o v e r c u r r e n t p r o t e c t i o n s

0.98 PFC

100% burn-in

C o m p l i a n t w i t h C E C a n d E n e r g y S ta r e f f i c i e n c y

l e v e l I V r e q u i r e m e n ts ( e x c e p t

≤

1 2 V o u t p u t m o d e l s )

‧

No load power consumption less than 0.5W

‧

Av e r a g e a c t i v e e f f i c i e n c y

≥

8 5 %

‧

C o m p l i a n t w i t h R o H S r e q u i r e m e n ts

‧

Saf et y Sta n da rd A ppr o va ls：

UL 60601-1

CSA C22.2 No. 601.1

TÜV EN60601-1

IN PUT S PE C IF ICAT ION S

I n p u t v o l ta g e :

Input frequency :

Input current :

Earth leakage current :

90 to 264VAC

47 to 63Hz

1.20A (rms) for 115VAC

0.60A (rms) for 230VAC

90µA max. @ 115VAC, 60Hz

150µA max. @ 230VAC, 50Hz

GENERAL SPECIFICATIONS

Switching frequency：

50 KHz - 110 KHz

Power factor：

0.98 Typical

Efficiency：

85% min. (78% min. for TMP90-05,

TMP90-06, TMP90-09 and TMP90-12)

Hold-up time：

15 msec minimum at 110VAC

Line regulation：

±0.5% maximum at full load

Inrush current：

40 amps @ 115VAC or 60 amps @

230VAC, @ 25ºC cold start

Withstand voltage：

4000VAC from input to output

1500VAC from input to ground

500VAC from output to ground

MTBF：

150,000 hours minimum at full load

at 25ºC ambient, calculated per

MIL-HDBK-217F

EMC Performance (IEC60601-1-2: 2001)

E N 5 5 0 11 :

FCC:

VCCI:

EN61000-3-2:

EN61000-3-3:

EN61000-4-2:

EN61000-4-3:

EN61000-4-4:

EN61000-4-5:

EN61000-4-6:

EN61000-4-8:

E N 6 1 0 0 0 - 4 - 11 :

Class B conducted, Class B radiated

Harmonic distortion, Class A and D

Line flicker

ESD, ±8KV air and ±6KV contact

Radiated immunity, 3V/m

Fast transient/burst, ±2KV

Surge, ±1KV diff, ±2KV com.

Conducted immunity, 3Vrms

Magnetic field immunity, 3A/m

Voltage dips, 30% reduction for 500ms,

60% reduction for 100ms and >95%

reduction for 10ms

OUTPUT SPECIFICATIONS

Output voltage/current：

Total output power：

Ripple and noise：

Over voltage protection：

Over current protection：

Temperature coefficient：

Transient response：

See rating chart

2% peak to peak maximum

Set at 112-140% of its nominal

output voltage

Protected to short circuit

conditions

±0.04%/ºC maximum

Maximum excursion of 4% or

better on all models, recovering

to 1% of final value within 500µs

after a 25% step load change

E N V IR O N M ENTA L SP E C IF ICATI O N S

Operating temperature

：

Storage temperature

：

Relative humidity

：

Derating：

0 ºC t o + 6 0 ºC

- 4 0 ºC t o + 8 5 ºC

5% to 95% non-condensing

Derate from 100% at +40ºC

linearly to 50% at +60ºC

Tumbler Technologies + TRUMPower

3350 Scott Blvd., Bldg. 13, Santa Clara, California 95054, USA

Phone: 408-988-6616

●

Fax: 408-988-6622

●

email: sales@trumpower.com

●

Website: www.TRUMPower.com
