Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
-40°C to 85°C
-55°C to 100°C
0.5W max.
Coaxial
ZX10-2-12+
50Ω
2 to 1200 MHz
Features
• low insertion loss, 0.5 dB typ.
• excellent amplitude unbalance
• very good phase unbalance
• small size
• low cost
• protected under U.S. Patent 6,790,049 & 6,963,255
CASE STYLE: FL905
Connectors Model
SMA
ZX10-2-12-S+
Price
$29.95
Qty.
(1-24)
Internal Dissipation (as a combiner) 0.125W max.
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
Applications
• cellular
• VHF/UHF receivers/transmitters
• radio
• defense
FREQ.
RANGE
(MHz)
2-1200
2-20
20-600
600-1000
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Electrical Specifications (T
AMB
=25°C)
INSERTION LOSS (dB)
ABOVE 3.0 dB
Typ. Max.
0.5
0.3
0.3
0.5
1.5
0.7
0.8
1.0
ISOLATION
(dB)
Typ.
21
29
25
21
Min
16
21
18
18
Outline Drawing
PHASE
UNBALANCE
(Degrees)
Max.
3.0
3.0
2.0
2.0
AMPLITUDE
UNBALANCE
(dB)
Max.
0.5
0.5
0.4
0.5
Typical Performance Data
Frequency
(MHz)
Total Loss
1
(dB)
S-1
2.00
5.00
14.00
32.00
50.00
3.30
3.25
3.24
3.25
3.26
3.28
3.32
3.36
3.39
3.49
3.57
3.62
3.65
3.75
3.86
S-2
3.12
3.11
3.11
3.11
3.13
3.15
3.21
3.25
3.29
3.43
3.53
3.61
3.62
3.74
3.88
Amplitude
Unbalance
(dB)
0.18
0.14
0.13
0.13
0.13
0.13
0.12
0.11
0.10
0.06
0.04
0.01
0.03
0.01
0.02
Isolation
(dB)
Phase
Unbalance
(deg.)
0.75
0.34
0.11
0.02
0.01
0.17
0.34
0.39
0.48
0.43
0.32
0.29
0.27
0.07
0.02
VSWR
S
VSWR
1
VSWR
2
27.33
31.03
32.84
32.75
32.34
30.09
26.11
24.65
23.47
21.36
20.62
20.51
20.38
20.29
20.33
1.03
1.02
1.02
1.02
1.02
1.03
1.05
1.06
1.07
1.08
1.09
1.09
1.09
1.09
1.08
ZX10-2-12+
ISOLATION
1.22
1.16
1.14
1.14
1.13
1.12
1.10
1.08
1.06
1.06
1.11
1.12
1.14
1.18
1.22
1.16
1.12
1.11
1.10
1.10
1.10
1.09
1.08
1.08
1.09
1.11
1.12
1.13
1.15
1.18
A
.74
18.80
H
.37
9.40
Outline Dimensions (
inch
)
mm
B
C
D
E
F
.90
22.86
J
--
--
.54
13.72
K
.122
3.10
.50
12.70
L
.496
12.60
.04
1.02
M
.106
2.69
.16
4.06
G
.29
7.37
140.00
320.00
410.00
500.00
740.00
900.00
950.00
1000.00
1100.00
1200.00
N
wt
.122 grams
3.10
20.0
1. Total Loss = Insertion Loss + 3dB splitter loss.
ZX10-2-12+
TOTAL LOSS
4.0
S-1
TOTAL LOSS (dB)
3.8
3.6
3.4
3.2
3.0
0
200
400
600
800
1000
1200
FREQUENCY (MHz)
S-2
35
ISOLATION (dB)
30
25
20
15
10
0
200
400
600
800
1000
1200
FREQUENCY (MHz)
ZX10-2-12+
VSWR
1.5
#S-VSWR
1.4
VSWR
1.3
1.2
1.1
1.0
0
200
400
#1-VSWR
#2-VSWR
electrical schematic
600
800
1000
1200
FREQUENCY (MHz)
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. G
M127604
ZX10-2-12+
ED-10145/1
HY/RS/CP
120130
