Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
-40°C to 85°C
-55°C to 100°C
1.0W max.
Coaxial
ZX10-2-98+
50Ω
4750 to 9800 MHz
Features
• low insertion loss, 0.3 dB typ.
• excellent amplitude unbalance
• very good phase unbalance
• small size
• low cost
• protected under U.S. Patent 6,790,049 & 6,963,255
CASE STYLE: FL905
Connectors Model
SMA
ZX10-2-98-S+
Price
$39.95
Qty.
(1-24)
Internal Dissipation (as a combiner) 0.125W max.
Permanent damage may occur if any of these limits are exceeded.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
Applications
• SHF
• communications
• defense
• cable tv relay
FREQ.
RANGE
(MHz)
f
L
-f
U
4750-9800
7000-9000
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Electrical Specifications (T
AMB
=25°C)
ISOLATION
(dB)
INSERTION LOSS (dB)
ABOVE 3.0 dB
PHASE
UNBALANCE
(Degrees)
Max.
9.0
8.0
Outline Drawing
AMPLITUDE
UNBALANCE
(dB)
Max.
0.5
0.4
Typ. Min.
23
23
10
18
Typ. Max.
0.3
0.3
1.2
0.8
Typical Performance Data
Frequency
(MHz)
Total Loss
(dB)
S-1
4750.00
4800.00
4850.00
5710.00
6140.00
6570.00
7000.00
7800.00
8200.00
8600.00
9000.00
9160.00
9480.00
9640.00
9800.00
3.62
3.56
3.60
3.38
3.27
3.23
3.26
3.29
3.33
3.41
3.45
3.44
3.50
3.58
3.64
1
Amplitude
Unbalance
(dB)
0.01
0.01
0.09
0.03
0.05
0.05
0.02
0.03
0.12
0.05
0.08
0.13
0.10
0.11
0.09
Isolation
(dB)
Phase
Unbalance
(deg.)
0.03
0.16
0.20
0.09
0.09
0.22
0.22
0.26
0.02
0.52
0.98
0.70
0.50
0.85
1.35
VSWR
S
VSWR
1
VSWR
2
S-2
3.63
3.56
3.69
3.36
3.32
3.18
3.28
3.32
3.45
3.45
3.53
3.57
3.60
3.69
3.73
11.68
11.85
12.02
14.69
16.37
18.46
21.45
32.30
31.01
23.48
20.33
19.49
17.81
17.38
16.51
1.97
2.01
1.93
1.49
1.30
1.16
1.09
1.29
1.25
1.32
1.41
1.37
1.43
1.44
1.42
1.31
1.35
1.38
1.33
1.29
1.24
1.23
1.29
1.22
1.12
1.10
1.07
1.29
1.25
1.40
1.28
1.33
1.35
1.31
1.25
1.20
1.19
1.26
1.23
1.18
1.17
1.17
1.31
1.28
1.39
Outline Dimensions (
inch
)
mm
A
.74
18.80
H
.37
9.40
B
.90
22.86
J
--
--
C
.54
13.72
K
.122
3.10
D
.50
12.70
L
.496
12.60
E
.04
1.02
M
.106
2.69
F
.16
4.06
G
.29
7.37
N
wt
.122 grams
3.10
20.0
1. Total Loss = Insertion Loss + 3dB splitter loss.
ZX10-2-98+
TOTAL LOSS
4.0
S-1
TOTAL LOSS (dB)
3.8
3.6
3.4
3.2
3.0
4700 5210 5720 6230 6740 7250 7760 8270 8780 9290 9800
FREQUENCY (MHz)
S-2
ZX10-2-98+
ISOLATION
35
ISOLATION (dB)
30
25
20
15
10
4700 5210 5720 6230 6740 7250 7760 8270 8780 9290 9800
FREQUENCY (MHz)
2.0
ZX10-2-98+
VSWR
#S-VSWR
#1-VSWR
#2-VSWR
1.8
VSWR
1.6
1.4
1.2
1.0
4700 5210 5720 6230 6740 7250 7760 8270 8780 9290 9800
FREQUENCY (MHz)
electrical schematic
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. G
M127604
ZX10-2-98+
ED-10280/1
HY/RS/CP/AM
100615
