3.0 WATT 2:1WIDE INPUT RANGE
DC/DC POWER MODULES
With Remote On/Off Option (Rectangle Package)
FEATURES
!
"
#
$
❺
3.0 Watt Isolated Output
2:1 Wide Input Range
High Conversion Efficiency
Continuous Short Circuit Protection
Remote ON/OFF Option
INPUT SPECIFICATIONS
&
Voltage ....................................12, 24, 48 Vdc
&
Voltage Range .........9-18, 18-36 & 36-72Vdc
&
Input Filter ........................................... Pi Type
GENERAL SPECIFICATIONS
&
&
&
&
Efficiency ...................................... Per Table
Switching Frequency ............... 100KHz Min.
Isolation Voltage: ..................... 500 Vdc Min.
Operating Temperature ........ -25 to +75
O
C
Derate Linearly to no load @ 100
O
C max.
&
Case Material:
500Vdc.......Non-Conductive Black Plastic
1.5kVdc & 3kVdc.....Black coated copper
with non-conductive base
&
EMI/RFI........................Conductive EMI Meet
EN55022 Class B
PACKAGE
OUTPUT SPECIFICATIONS
Voltage ........................................... Per Table
Initial Voltage Accuracy ................ ±2% Max
Voltage Stability ......................... ±0.05% max
Ripple & Noise .................... 100/150mV p-p
Load Regulation (10 to 100% Load)
Single Output Units:
±0.5%
Dual Output Units:
±1.0%
&
Line Regulation ........................... ±0.5% typ.
&
Temp Coefficient ...................... ±0.05% /
O
C
&
Short Circuit Protection ........... Continuous
&
&
&
&
&
PIN ASSIGNMENTS
REMOTE ON/OFF CONTROL
PHYSICAL DIMENSIONS
DIMENSIONS IN inches (mm)
P
PDCx03xxxx
YYWW
M
1.25
(31.8)
.50
(12.7)
Logic
Ec-On
Ec-Off
Shutdown Idle Current
Input Resistance
Control Common
500VDC
PIN
#
1
2
3
5
9
10
11
12
13
14
15
16
22
23
24
SINGLE
OUTPUT
+ INPUT
NC
NC
NP
NP
- OUTPUT
+ OUTPUT
- INPUT
- INPUT
+ OUTPUT
- OUTPUT
NP
NC
NC
+ INPUT
DUAL
OUTPUTS
+INPUT
- OUTPUT
COMMON
NP
NP
COMMON
+ OUTPUT
- INPUT
- INPUT
+ OUTPUT
COMON
NP
COMMON
- OUTPUT
+ INPUT
CMOS or Open Collector TTL
>+5.5VDC or Open Circuit
<1.8VDC
10mA
100 Ohm
Referenced to Input Minus
1500VDC & 3000VDC
PIN
#
1
2
3
5
9
10
11
12
13
14
15
16
22
23
24
SINGLE
OUTPUT
NP
- INPUT
- INPUT
NP
NC
NC
NC
NP
NP
+ OUTPUT
NC
- OUTPUT
+ INPUT
+ INPUT
NP
DUAL
OUTPUTS
NP
- INPUT
- INPUT
R.ON/OFF
COMMON
NC
- OUTPUT
NP
NP
+ OUTPUT
NC
COMMON
+ INPUT
+ INPUT
NP
PDCx0302x 12/00
.15
(3.8)
.20
(5.1)
1 2 3
5
.10
(2.5)
9 10 11 12
.08
(2.0)
.60
.80
(15.24) (20.3)
24 23 22
16 15 14 13
Specifications subject to change without notice.
20381 BARENTS SEA CIRCLE, LAKE FOREST, CA 92630
•
TEL: (949) 452-0511
•
FAX: (949) 452-0512
•
http://www.premiermag.com
1
3.0 WATT 2:1WIDE INPUT RANGE
DC/DC POWER MODULES
With Remote On/Off Option (Rectangle Package)
ELECTRICAL SPECIFICATIONS AT 25
O
C - OPERATING TEMPERATURE RANGE -25
O
C TO +75
O
C
PART
NUMBER
(NOTE #1)
INPUT VOLTAGE OUTPUT
Previous
VOLTAGE
Premier Magnetic
NOMINAL RANGE
(Vdc)
Part #
(NOTE #2)
OUTPUT
CURRENT
(mAdc)
INPUT
CURRENT
NO LOAD
FULL LOAD
mA
mA
TYPICAL
EFFICIENCY
PDCS03021
PDCS03022
PDCS03023
PDCS03024
PDCD03022
PDCD03023
PDCD03024
PDCS03025
PDCS03026
PDCS03027
PDCS03028
PDCD03026
PDCD03027
PDCD03028
PDCS03029
PDCS03030
PDCS03031
PDCS03032
PDCD03030
PDCD03031
PDCD03032
B5AS1203NX
B5AS1205NX
B5AS1212NX
B5AS1215NX
B5AD1205NX
B5AD1212NX
B5AD1215NX
B5AS2403NX
B5AS2405NX
B5AS2412NX
B5AS2415NX
B5AD2405NX
B5AD2412NX
B5AD2415NX
B5AS4803NX
B5AS4805NX
B5AS4812NX
B5AS4815NX
B5AD4805NX
B5AD4812NX
B5AD4815NX
12
12
12
12
12
12
12
24
24
24
24
24
24
24
48
48
48
48
48
48
48
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
36-72
3.3
5
12
15
±5
±12
±15
3.3
5
12
15
±5
±12
±15
3.3
5
12
15
±5
±12
±15
600
600
250
200
±300
±125
±100
600
600
250
200
±300
±125
±100
600
600
250
200
±300
±125
±100
7.5
7.5
7.5
7.5
12
12
12
5
5
5
5
7.5
7.5
7.5
3
2
2
2
3
3
3
226
340
320
330
340
330
330
113
168
156
156
168
156
160
55
82
82
82
82
82
82
73 %
73 %
78 %
76 %
73 %
76 %
75 %
73 %
74 %
80 %
80 %
74 %
80 %
80 %
76 %
76 %
77 %
77 %
76 %
76 %
76 %
NOTE #1:
PDCx030xx_ : BLANK FOR STANDARD PART WITH ISOLATION = 500VDC
PDCx030xxK : ADD "K" FOR PART WITH ISOLATION = 1500VDC
PDCx030xxQ : ADD "Q" FOR PART WITH ISOLATION = 3000VDC
PDCx030xxR : ADD "R" FOR PART WITH ISOLATION = 3000VDC AND REMOTE ON/OFF
NOTE #2:
(FOR PREVIOUS PREMIER MAGNETICS PART #)
B5AXXXXXNX : FOR STANDARD PART WITH ISOLATION = 500VDC
B5AXXXXXNM : FOR PART WITH ISOLATION = 1500VDC
B5AXXXXXNT : FOR PART WITH ISOLATION = 3000VDC
B5AXXXXXYT : FOR PART WITH ISOLATION = 3000VDC AND REMOTE ON/OFF
Specifications subject to change without notice.
PDCx0302x 12/00
20381 BARENTS SEA CIRCLE, LAKE FOREST, CA 92630
•
TEL: (949) 452-0511
•
FAX: (949) 452-0512
•
http://www.premiermag.com
2
