3.0 WATT 2:1WIDE INPUT RANGE
DC/DC POWER MODULES
FEATURES
!
"
#
$
Extended Temperature (Rectangle Package)
INPUT SPECIFICATIONS
%
Voltage .................................5,12, 24, 48 Vdc
%
Voltage Range.. 4.5-9,9-18,18-36, 36-72Vdc
%
Input Filter ........................................... Pi Type
GENERAL SPECIFICATIONS
%
%
%
%
%
3.0 Watt Isolated Output
2:1 Wide Input Range
Continuous Short Circuit Protection
Extended Temperature
Efficiency ...................................... Per Table
Operating Frequency ............... 50KHz Min.
Isolation Voltage: ..................... 500 Vdc Min.
Operating Temperature ........ -40 to +80
O
C
Efficiency ................................... up to 80%
OUTPUT SPECIFICATIONS
%
Voltage ........................................... Per Table
%
Voltage Stability ......................... ±0.05% max
%
Ripple & Noise Vout = 5~9V....... 100mV p-p
Vout = 12~15V....................1% Of Vout
%
Load Regulation ......................... ±0.2% typ.
%
Line Regulation ........................... ±0.1% typ.
OUTPUT
INPUT
OUTPUT
VOLTAGE VOLTAGE CURRENT
(Vdc)
(Vdc)
(mA max.)
ELECTRICAL SPECIFICATIONS AT 25
O
C - OPERATING TEMPERATURE RANGE -40
O
C TO +80
O
C
PART
NUMBER
(SINGLE OUTPUT)
OUTPUT
OUTPUT
INPUT
VOLTAGE VOLTAGE CURRENT
(Vdc)
(mA max.)
(Vdc)
%EFF
PART
NUMBER
(DUAL OUTPUT)
%EFF
PDCS03051
PDCS03052
PDCS03053
PDCS03054
PDCS03056
PDCS03057
PDCS03058
PDCS03059
PDCS03061
PDCS03062
PDCS03063
PDCS03064
PDCS03066
PDCS03067
PDCS03068
PDCS03069
5
5
5
5
12
12
12
12
24
24
24
24
48
48
48
48
5
9
12
15
5
9
12
15
5
9
12
15
5
9
12
15
600
333
250
200
600
333
250
200
600
333
250
200
600
333
250
200
65
70
72
73
66
75
77
75
78
79
80
80
72
75
76
80
PDCD03051
PDCD03052
PDCD03053
PDCD03054
PDCD03056
PDCD03057
PDCD03058
PDCD03059
PDCD03061
PDCD03062
PDCD03063
PDCD03064
PDCD03066
PDCD03067
PDCD03068
PDCD03069
5
5
5
5
12
12
12
12
24
24
24
24
48
48
48
48
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±5
±9
±12
±15
±300
±167
±125
±100
±300
±167
±125
±100
±300
±167
±125
±100
±300
±167
±125
±100
65
70
71
72
65
74
71
75
80
75
79
80
77
75
74
76
PACKAGE
.10
(2.5)
PHYSICAL DIMENSIONS
DIMENSIONS IN inches (mm)
1
2
3
PIN ASSIGNMENTS
500 VDC
PIN
#
1
2
3
10
11
12
13
14
15
22
23
24
SINGLE
OUTPUT
+INPUT
NP
NP
-OUTPUT
+OUTPUT
- INPUT
- INPUT
+OUTPUT
-OUTPUT
NP
NP
+INPUT
DUAL
OUTPUTS
+INPUT
- OUTPUT
COMMON
COMMON
+OUTPUT
- INPUT
- INPUT
+OUTPUT
COMMON
COMMON
-OUTPUT
+INPUT
PDCx0305x 12/00
24
23
22
P
PDCx03xxxx
M
YYWW
.70
(17.78)
15
14
13
10
11
12
1.25
(31.8)
.60
(15.24)
.80
(20.3)
.15
(3.8)
.50
(12.7)
Specifications subject to change without notice.
*NP-NO PIN
*NC-NO CONNECTION WITH PIN
20381 BARENTS SEA CIRCLE, LAKE FOREST, CA 92630
•
TEL: (949) 452-0511
•
FAX: (949) 452-0512
•
http://www.premiermag.com
1
