Digital Signal Processor, 0-Ext Bit, 20MHz, CMOS, PQCC84, PLASTIC, LCC-84
| Parameter Name | Attribute value |
| Maker | Zilog, Inc. |
| Parts packaging code | LCC |
| package instruction | QCCJ, |
| Contacts | 84 |
| Reach Compliance Code | unknown |
| Address bus width | |
| barrel shifter | NO |
| boundary scan | NO |
| maximum clock frequency | 20 MHz |
| External data bus width | |
| Format | FIXED POINT |
| Internal bus architecture | SINGLE |
| JESD-30 code | S-PQCC-J84 |
| length | 29.3116 mm |
| low power mode | NO |
| Number of terminals | 84 |
| Maximum operating temperature | 70 °C |
| Minimum operating temperature | |
| Package body material | PLASTIC/EPOXY |
| encapsulated code | QCCJ |
| Package shape | SQUARE |
| Package form | CHIP CARRIER |
| Certification status | Not Qualified |
| Maximum seat height | 4.57 mm |
| surface mount | YES |
| technology | CMOS |
| Temperature level | COMMERCIAL |
| Terminal form | J BEND |
| Terminal pitch | 1.27 mm |
| Terminal location | QUAD |
| width | 29.3116 mm |
| uPs/uCs/peripheral integrated circuit type | DIGITAL SIGNAL PROCESSOR, OTHER |
| Base Number Matches | 1 |
| Z89C6820VSCXXXX | Z89C6820VSC | Z89C6720VSCXXXX | Z89C6720VSC | Z8916724FSCXXXX | |
|---|---|---|---|---|---|
| Description | Digital Signal Processor, 0-Ext Bit, 20MHz, CMOS, PQCC84, PLASTIC, LCC-84 | Digital Signal Processor, 0-Ext Bit, 20MHz, CMOS, PQCC84, PLASTIC, LCC-84 | Digital Signal Processor, 0-Ext Bit, 20MHz, CMOS, PQCC84, PLASTIC, LCC-84 | Digital Signal Processor, 0-Ext Bit, 20MHz, CMOS, PQCC84, PLASTIC, LCC-84 | Digital Signal Processor, 0-Ext Bit, 24MHz, CMOS, PQFP100, PLASTIC, QFP-100 |
| Maker | Zilog, Inc. | Zilog, Inc. | Zilog, Inc. | Zilog, Inc. | Zilog, Inc. |
| Parts packaging code | LCC | LCC | LCC | LCC | QFP |
| package instruction | QCCJ, | QCCJ, | QCCJ, | QCCJ, | QFP, |
| Contacts | 84 | 84 | 84 | 84 | 100 |
| Reach Compliance Code | unknown | unknown | unknown | unknown | unknown |
| barrel shifter | NO | NO | NO | NO | NO |
| boundary scan | NO | NO | NO | NO | NO |
| maximum clock frequency | 20 MHz | 20 MHz | 20 MHz | 20 MHz | 24 MHz |
| Format | FIXED POINT | FIXED POINT | FIXED POINT | FIXED POINT | FIXED POINT |
| JESD-30 code | S-PQCC-J84 | S-PQCC-J84 | S-PQCC-J84 | S-PQCC-J84 | R-PQFP-G100 |
| length | 29.3116 mm | 29.3116 mm | 29.3116 mm | 29.3116 mm | 20 mm |
| Number of terminals | 84 | 84 | 84 | 84 | 100 |
| Package body material | PLASTIC/EPOXY | PLASTIC/EPOXY | PLASTIC/EPOXY | PLASTIC/EPOXY | PLASTIC/EPOXY |
| encapsulated code | QCCJ | QCCJ | QCCJ | QCCJ | QFP |
| Package shape | SQUARE | SQUARE | SQUARE | SQUARE | RECTANGULAR |
| Package form | CHIP CARRIER | CHIP CARRIER | CHIP CARRIER | CHIP CARRIER | FLATPACK |
| Certification status | Not Qualified | Not Qualified | Not Qualified | Not Qualified | Not Qualified |
| Maximum seat height | 4.57 mm | 4.57 mm | 4.57 mm | 4.57 mm | 3.1 mm |
| surface mount | YES | YES | YES | YES | YES |
| technology | CMOS | CMOS | CMOS | CMOS | CMOS |
| Terminal form | J BEND | J BEND | J BEND | J BEND | GULL WING |
| Terminal pitch | 1.27 mm | 1.27 mm | 1.27 mm | 1.27 mm | 0.65 mm |
| Terminal location | QUAD | QUAD | QUAD | QUAD | QUAD |
| width | 29.3116 mm | 29.3116 mm | 29.3116 mm | 29.3116 mm | 14 mm |
| uPs/uCs/peripheral integrated circuit type | DIGITAL SIGNAL PROCESSOR, OTHER | DIGITAL SIGNAL PROCESSOR, OTHER | DIGITAL SIGNAL PROCESSOR, OTHER | DIGITAL SIGNAL PROCESSOR, OTHER | DIGITAL SIGNAL PROCESSOR, OTHER |
| Internal bus architecture | SINGLE | - | SINGLE | - | SINGLE |
| low power mode | NO | - | NO | - | NO |
| Maximum operating temperature | 70 °C | - | 70 °C | - | 70 °C |
| Temperature level | COMMERCIAL | - | COMMERCIAL | - | COMMERCIAL |
