PSB Series Extended Data Sheet
Positive Switching Regulators (Rugged)
Input voltage up to 144 V DC
Single output of 5.1 to 48 V DC
No input to output isolation
•
High efficiency up to 96%
•
Extremely wide input voltage range
•
Very good dynamic properties
•
Input undervoltage lock-out
•
External output voltage adjustment and inhibit
•
2 temperature ranges
32
1.3"
69
2.7"
106
4.2"
•
Continuous no-load and short-circuit proof
•
No derating
Safety according to IEC/EN 60950
Summary
The PSB series of positive switching regulators is de-
signed as power supply modules for electronic systems.
Their major advantages include a high level of efficiency
that remains virtually constant over the entire input range,
high reliability, low ripple and excellent dynamic response.
Modules with input voltages up to 144 V are specially de-
signed for battery driven mobile applications. The case
design allows operation at nominal load up to 71°C with-
out additional cooling.
Model Selection and Key Data
Table 1: Type survey
Output
voltage
V
o nom
[V]
5.1
12
15
24
36
48
1
2
3
Output
Input
current
voltage range
I
o nom
[A]
I
o max
[A]
1
V
i
[V]
2
4
3
3
3
3
3
5
4
4
4
4
4
15
–
144
18
–
144
22
–
144
31
–
144
44
–
144
58
–
144
Input
voltage
V
i nom
[V]
60
60
60
60
80
80
Efficiency
h
min
[%]
76
87
89
92
94
95
3
Type
designation
PSB 5A4-7iR
PSB 123-7iR
PSB 153-7iR
PSB 243-7iR
PSB 363-7iR
PSB 483-7iR
Options
h
typ
[%]
80
89
90
94
95
96
-9, L, P, C
I
o max
for
V
i
-80 V or reduced temperature. See:
Thermal Considerations.
Surges up to 156 V for 2 s. See also:
Electrical Input Data:
D
V
io min
.
Efficiency at
V
i nom
and
I
o nom
.
Non standard input/output configurations or special custom adaptions are available on request.
See also:
Commercial Information: Inquiry Form for Customized Power Supply.
