High Frequency
Surface Mount Attenuators
RFAXXX-0 Series
•
RoHS compliant
•
Power dissipation up to 150W
•
High frequency operation up to 3GHz
The RFAXXX-0 series power attenuator has a low VSWR from DC to 3GHz. High frequency performance
combined with high power dissipation make this an ideal RF power attenuator. Typical applications are RF and
microwave power amplifiers, RF transmitters, receivers and meters where a reduction in power is needed while
maintaining transmission line characteristic impedances.
Electrical Data
RFA100-0xx
Power Rating @70°C
Impedance
Frequency Range
Operating Temperature Range
Attenuation
Attenuation Tolerance at DC
Types 010, 020, 030
Terminations
Types 012, 022, 032
Gold (Au) plated copper
100W (Heatsinked)
50Ω
DC - 3GHz
-55°C to +155°C
20dB, 30dB
±0.4 dB
Tin (Sn) plated copper
RFA150-0xx
150W (Heatsinked)
General Note
IRC reserves the right to make changes in product specification without notice or liability.
All information is subject to IRC’s own data and is considered accurate at time of going to print.
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
A subsidiary of
TT electronics plc
RFAXXX-0 Series Issue February 2009 Sheet 1 of 4
High Frequency
Surface Mount Attenuators
Physical Data
RFA100 010, RFA100 020, RFA100 030
RFA150 010, RFA150 020, RFA150 030
RFA100 012, RFA100 022, RFA100 032
RFA150 012, RFA150 022, RFA150 032
E
D
E
F
F
C
A
B
D
E
B
E
C
(6.0)
A
(6.0)
Dimensions (mm)
Model and Type
RFA100 010 / 012
RFA100 020 / 022
RFA100 030 / 032
RFA150 010 / 012
RFA150 020 / 022
RFA150 030 / 032
A
B
C
D
1.0 ± 0.3
1.0 ± 0.3
1.1 ± 0.3
1.0 ± 0.3
1.0 ± 0.3
1.1 ± 0.3
E
F*
5.84 ± 0.15
5.84 ± 0.25
5.72 ± 0.25
7.62 ± 0.15
7.62 ± 0.25
6.35 ± 0.25
8.89 ± 0.15
8.89 ± 0.25
8.90 ± 0.25
11.43 ± 0.15
11.43 ± 0.25
9.52 ± 0.25
1.1 max
1.1 max
1.1 max
1.1 max
1.1 max
1.1 max
0.3 ± 0.1
0.3 ± 0.1
0.3 ± 0.1
0.3 ± 0.1
0.3 ± 0.1
0.3 ± 0.1
(1.5)
(1.05)
(1.1)
(1.5)
(1.05)
(1.1)
*Note: Dimension F does not apply to types 012, 022 and 032.
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
RFAXXX-0 Series Issue February 2009 Sheet 2 of 4
High Frequency
Surface Mount Attenuators
Frequency Performance Data
RFA100 030 20DB (S11) Impedance
CH1
S 11
hp
RFA100 030 30DB (S11) Impedance
CH1
S 11
hp
1 U FS
1:
49.381
W
1.1348
W
180.06 pH
1 U FS
1:
47.074
W
0.416
W
66.211 pH
1 002. 999 970 MHz
2: 50.52
W
2.6367
W
1.5 GHz
3: 52.801
W
3.4609
W
2 GHz
PRm
Cor
1 000. 000 000 MHz
2: 46.797
W
2.9102
W
1.5 GHz
3: 48.965
W
5.1797
W
2 GHz
PRm
Cor
↑
1
234
5
4: 56.295
W
2.291
W
2.5 GHz
5: 59.516
W
-1.7363
W
3 GHz
↑
1
2345
4: 52.484
W
5.5547
W
2.5 GHz
5: 56.547
W
4.0684
W
3 GHz
START
.030 000 MHz
STOP 3 000. 000 000 MHz
START
.030 000 MHz
STOP 3 000. 000 000 MHz
RFA150 030 20DB Impedance
CH1
S 11
hp
RFA150 030 30DB Impedance
441.9 pH
1 U FS
1:
50.135
W
2.7773
W
CH1
S 11
hp
1 U FS
1:
49.811
W
1.4063
W
222.94 pH
1 000. 299 997 MHz
2: 51.611
W
5.4629
W
1.5 GHz
3: 56.348
W
7.5996
W
2 GHz
1 003. 899 961 MHz
2: 50.488
W
3.3457
W
1.5 GHz
3: 53.211
W
5.4258
W
2 GHz
PRm
Cor
PRm
Cor
↑
1
234
5
4: 63.48
W
6.7559
W
2.5 GHz
5: 73.035
W
0.4766
W
3 GHz
↑
1
23 4 5
4: 53.67
W
5.0176
W
2.5 GHz
5: 65.172
W
0.957
W
3 GHz
START
.030 000 MHz
STOP 3 000. 000 000 MHz
START
.030 000 MHz
STOP 3 000. 000 000 MHz
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
RFAXXX-0 Series Issue February 2009 Sheet 3 of 4
High Frequency
Surface Mount Attenuators
Environmental Data
Test Condition
Load Life
Moisture Load
Life
Solder Heat
Resistance
Solderability
1000 Hours, 70°C
1000 Hours, 40°C
95% RH
350°C, 3 sec.
Maximum
±1.0%
±1.0%
±1.0%
>95% coverage
Power Derating Curve
100
% Of Rated Power
60
0
25
70
125
Ambient Temperature (°C)
Ordering Data
Prefix
Model
Type
HFR - RFA100LF - 010 - 20dB
RFA100LF; RFA150LF
010; 020; 030 = Tin plated copper pads
012; 022; 032 = Tin plated copper-alloy beam leads
Attenuation
20dB; 30dB
© IRC Advanced Film Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
RFAXXX-0 Series Issue February 2009 Sheet 4 of 4
