XZAG75W: DescriptionSingle Color LED, Green, Water Clear, 2.3mm, 3.50 X 2 MM, 1.30 MM HEIGHT, SURFACE MOUNT PACKAGE-2; CategoryLED optoelectronic/LED photoelectric; File Size91KB，3 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/

Download Datasheet Parametric View All

XZAG75W Overview

Single Color LED, Green, Water Clear, 2.3mm, 3.50 X 2 MM, 1.30 MM HEIGHT, SURFACE MOUNT PACKAGE-2

XZAG75W Parametric

Parameter Name	Attribute value
Maker	SUNLED
package instruction	3.50 X 2 MM, 1.30 MM HEIGHT, SURFACE MOUNT PACKAGE-2
Reach Compliance Code	compliant
ECCN code	EAR99
color	GREEN
Configuration	SINGLE
Maximum forward current	0.03 A
Lens type	WATER CLEAR
Nominal luminous intensity	148.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	1.3 mm
method of packing	BULK
peak wavelength	500 nm
shape	RECTANGULAR
size	2.3 mm
surface mount	YES
Terminal pitch	3.1 mm
perspective	120 deg
Base Number Matches	1

Preview

Download Datasheet

View All

3.5x2.0mm SMD CHIP LED LAMP

XZAG75W

SUN LED

Email

: sales@us.sunled.com

Web Site : www.sunled.com

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±0.2(0.0079")

unless otherwise noted.

Ab s o l u t e m a x i m u m r a t i n g s

( T

A

=25

°

C)

Reverse voltage

Forward current

Forward current (peak)

1/10Duty cycle

0.1ms pulse width

Power dissipation

Operating temperature

Storage temperature

V

R

I

F

i

FS

P

T

A

Tstg

AG

( I n G a N)

5

30

150

110

-40 ~ +85

Un i t

Op e r a t i n g Ch a r a c t e r i s t i c s

( T

A

=25

°

C)

Forward voltage (typ.)

(I F=20mA)

Forward voltage (max.)

(I F=20mA)

Reverse current

(VR=5V)

Wavelength at peak

emission

(I F=20mA)

Wavelength at Dominate

emission

(I F=20mA)

Spectral Line half-width

(I F=20mA)

Capacitance

(VF=0V, f=1MHz)

AG

( I n G a N)

Un i t

V

mA

mW

°C

V

F

V

F

I

R

3.6

4.4

10

V

uA

λ

peak

500

nm

λD

505

nm

∆λ

C

30

56

nm

pF

P art

Nu m b e r

Em i t t i n g

Co l o r

Em i t t i n g

Ma te ria l

L e n s -c o l o r

L u min o u s

In t e n si t y

( I F = 20m A )

mc d

min .

ty p .

70

148

Wa v e l e n g t h

nm

λ

P

Vi e w i n g

An g l e

2θ1/2

θ

XZAG75W

Green

I nGaN

Water Clear

500

120°

Published Date :OCT 23,2002

Drawing No: XDSA1513

V2

Checked : B.L.LIU

3-1
