LH1562F3 datasheet, PDF - EEWORLD Datasheet

LH1562F3: DescriptionLiquid Crystal Driver, 240-Segment, SLIM, TCP; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size203KB，1 Pages; ManufacturerSHARP; Websitehttp://sharp-world.com/products/device/

Download Datasheet Parametric Compare View All

LH1562F3 Overview

Liquid Crystal Driver, 240-Segment, SLIM, TCP

Parameter Name	Attribute value
Maker	SHARP
package instruction	SLIM, TCP
Reach Compliance Code	unknown
data entry mode	PARALLEL
display mode	DOT MATRIX
Interface integrated circuit type	LIQUID CRYSTAL DISPLAY DRIVER
JESD-30 code	X-XUUC-N
Multiplex display function	NO
Number of functions	1
Number of segments	240
Package body material	UNSPECIFIED
encapsulated code	DIE
Package shape	UNSPECIFIED
Package form	UNCASED CHIP
Certification status	Not Qualified
Maximum supply voltage	5.5 V
Minimum supply voltage	2.5 V
Nominal supply voltage	2.5 V
Supply voltage 1-max	42 V
surface mount	YES
Terminal form	NO LEAD
Terminal location	UPPER
minfmax	20 MHz
Base Number Matches	1

	LH1562F3	LH1562F	LH1560F2
Description	Liquid Crystal Driver, 240-Segment, SLIM, TCP	Liquid Crystal Driver, 240-Segment, SLIM, TCP	Liquid Crystal Driver, 160-Segment, SLIM, TCP
package instruction	SLIM, TCP	SLIM, TCP	SLIM, TCP
Reach Compliance Code	unknown	unknown	unknown
data entry mode	PARALLEL	PARALLEL	PARALLEL
display mode	DOT MATRIX	DOT MATRIX	DOT MATRIX
Interface integrated circuit type	LIQUID CRYSTAL DISPLAY DRIVER	LIQUID CRYSTAL DISPLAY DRIVER	LIQUID CRYSTAL DISPLAY DRIVER
JESD-30 code	X-XUUC-N	X-XUUC-N	X-XUUC-N
Multiplex display function	NO	NO	NO
Number of functions	1	1	1
Number of segments	240	240	160
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
encapsulated code	DIE	DIE	DIE
Package shape	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Package form	UNCASED CHIP	UNCASED CHIP	UNCASED CHIP
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum supply voltage	5.5 V	5.5 V	5.5 V
Minimum supply voltage	2.5 V	2.5 V	2.5 V
Nominal supply voltage	2.5 V	2.5 V	2.5 V
Supply voltage 1-max	42 V	42 V	42 V
surface mount	YES	YES	YES
Terminal form	NO LEAD	NO LEAD	NO LEAD
Terminal location	UPPER	UPPER	UPPER
minfmax	20 MHz	20 MHz	14 MHz
Maker	SHARP	-	SHARP
Base Number Matches	1	1	-
