RoHS
High Frequency Chip Inductors
Dimensions:
Inches
(mm)
0.063±0.006
(1.60±0.15)
HFC05
0.031±0.006
(0.80±0.15)
0.031±0.006
(0.80±0.15)
0.012±0.008
(0.30±0.20)
0.023
(0.60)
0.031
(0.79)
0.041
(1.04)
Allied
Part
Number
Inductance Tolerance
Q
Q
(nh)
Typical
Typical
(%)
@100MHz
@100MHz @800MHz
SRF
Typical
(MHz)
DCR
Max.
(Ω)
IDC
Max.
(mA)
Features
• 0603 EIA size for high board density
applications.
• Excellent Q and SRF characteristics
for high frequency applications.
•
Cost effective monolithic construction
Electrical
Inductance range:
1.0nh to 270nh
Tolerance:
use S for ± .3nh, J for 5%,
K for 10%
Test Frequency:
Inductance and Q tested
at 100MHz, 200mv with HP4191A
Impedance Analyzer + HP16197A
Inductance vs Freq. Characteristics
measured on HP4191A
Q vs Frequency Characteristics
measured on HP4191A
SRF measured with HP4291A &
HP16197A
DCR measured with Chen Hwa CH502BC
or HP4338B
IDC measured with HP4291-A + HP6632A
Mechanical
Operating Temperature:
-55ºC-125ºC
Storage Temperature:
Under 25ºC,
Humidty 40% - 65%
Solderability:
90% terminal coverage
Test Condition:
Pre heat: 150ºC 1min.
Solder composition:
Sn/Ag3.0/Cu.0.5 (Pb free)
Solder temp: 245ºC±5ºC (pb Free)
Immersion time: 4 ± 1 sec.
Resistance to solder heat:
No damage to part
Test Condition
Pre heat: 150ºC. 1min.
Solder composition:
Sn/Ag3.0/Cu.0.5 (Pb free)
Solder temp: 260ºC±5ºC (pb Free)
Immersion time: 10 ± 1 sec.
Physical
Packaging:
4000 pieces per
7 inch
reel.
HFC05-1N0S-RC
HFC05-1N2S-RC
HFC05-1N5S-RC
HFC05-1N6S-RC
HFC05-1N7S-RC
HFC05-1N8S-RC
HFC05-2N2S-RC
HFC05-2N5S-RC
HFC05-2N7S-RC
HFC05-3N3K-RC
HFC05-3N9K-RC
HFC05-4N3K-RC
HFC05-4N7K-RC
HFC05-5N1K-RC
HFC05-5N4K-RC
HFC05-5N6K-RC
HFC05-6N2K-RC
HFC05-6N8K-RC
HFC05-7N5K-RC
HFC05-8N2K-RC
HFC05-10NK-RC
HFC05-11N5K-RC
HFC05-12NK-RC
HFC05-15NK-RC
HFC05-18NK-RC
HFC05-22NK-RC
HFC05-27NK-RC
HFC05-33NK-RC
HFC05-39NK-RC
HFC05-47NK-RC
HFC05-56NK-RC
HFC05-62NK-RC
HFC05-68NK-RC
HFC05-75NK-RC
HFC05-82NK-RC
HFC05-100NK-RC
HFC05-120NK-RC
HFC05-150NK-RC
HFC05-180NK-RC
HFC05-220NK-RC
HFC05-270NK-RC
1.0
1.2
1.5
1.6
1.7
1.8
2.2
2.5
2.7
3.3
3.9
4.3
4.7
5.1
5.4
5.6
6.2
6.8
7.5
8.2
10
11.5
12
15
18
22
27
33
39
47
56
62
68
75
82
100
*120
*150
*180
*220
***270
0.3nh
0.3nh
0.3nh
0.3nh
0.3nh
0.3nh
0.3nh
0.3nh
0.3nh
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
12
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
15
15
15
17
17
18
18
18
18
18
18
18
18
18
*14
*15
*15
*15
*13
50
65
47
47
47
51
46
46
45
51
52
52
41
52
41
41
44
44
44
44
45
45
46
48
48
45
43
39
***37
***35
***32
***34
***34
***32
***32
***20
**23
**23
**21
**20
**14
10000
10000
8000
8000
8000
8000
7200
6200
6200
5200
5000
4750
4750
4100
4100
4100
3750
3750
3300
3300
3000
2800
2600
2500
2400
2000
1900
1600
1400
1300
1100
1050
1050
900
900
770
650
550
520
500
470
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.10
0.12
0.14
0.16
0.16
0.18
0.18
0.18
0.22
0.22
0.24
0.24
0.26
0.30
0.28
0.32
0.35
0.40
0.45
0.55
0.60
0.70
0.75
0.85
0.85
1.00
1.00
1.20
2.30
2.40
2.70
2.80
3.50
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
600
1000
600
600
600
500
500
400
400
400
400
400
400
300
300
300
300
250
250
250
150
*at 50MHz. **at 300MHZ. ***at 500MHz.
Additional Inductance values available upon request.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 3/23/09
www.alliedcomponents.com
