RoHS
Low Resistance Chip Inductors
Dimensions:
Inches
(mm)
0.126±0.012
(3.20±0.30)
0.098±0.008
(2.49±0.20)
0.098±0.008
(2.49±0.20)
0.098±0.008
(2.49±0.20)
0.126±0.012
(3.20±0.30)
LRC20
0.079±0.008
(2.01±0.20)
0.049
(1.24)
0.078
(1.98)
(MHz)
Allied
Part
Number
LRC20-1R0M-RC
LRC20-2R2M-RC
LRC20-3R3M-RC
LRC20-3R9M-RC
LRC20-4R7M-RC
LRC20-6R8M-RC
Inductance
(µh)
Tolerance
(%)
Test
Freq.
(MHz)
1
1
1
1
1
1
SRF
Min.
(MHz)
96
64
60
50
43
30
DCR
Max.
(Ω)
.120
.170
.195
.208
.260
.338
Rated
Current
(mA)
1000
600
600
500
450
400
0.039
(.991)
0.039
(.991)
0.039
(.991)
Features
• Miniature SMT wire-wound open
magnetic path construction inductors
with low DCR, high current capacity
and High Impedance Characteristics.
• Excellent solder heat resistance for
flow and reflow soldering methods.
• Excellent for use as choke coils
in DC/DC converter and DC power
supply circuits.
Electrical
Inductance Range:
1.0µh to 560µh.
Tolerance:
For 20% use M, 10% use K
and 5% use J as part number suffix.
Test Frequency:
Inductance measured
1.0
2.2
3.3
3.9
4.7
6.8
20
20
20
20
20
20
LRC20-100K-RC
LRC20-220K-RC
LRC20-330K-RC
10
22
33
10
10
10
1
1
1
26
19
15
.580
.930
1.43
300
250
200
LRC20-470K-RC
47
10
1
15
1.69
170
on an HP4192 at 1MHz for all values
except 470µh and 560µh. Which are
ll
LRC20-560K-RC
56
10
1
12
2.99
150
tested at 1KHz.
LRC20-101K-RC
100
10
1
10
4.60
100
Operating Temp. Range:
i-25°
to +85°C.
Rated Current:
Based on Temperature
rise not to exceed 35ºC. Inductance Drop
10% typical.
Resistance to Soldering Heat:
Pre heat:
150ºC ± 10ºC / 1-2 min. Solder temp:
260ºC ± 5ºC for 10 sec. ± 1 sec.
Physical
Packaging:
2000 pieces per 7 inch reel.
7500 pieces per 13 inch reel.
LRC20-221K-RC
LRC20-331K-RC
220
330
10
10
1
1
6.8
5.6
11.0
13.0
70
60
LRC20-391K-RC
LRC20-471K-RC
LRC20-561K-RC
390
470
560
10
10
10
1
*1
*1
5.0
5.0
5.0
22.0
25.0
29.0
60
60
60
*Tested at 1KHz.
Available in tighter tolerances.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
Revised 03-25-08
www.alliedcomponents.com
