RoHS
LS10
0.60
(1.52)
0.20
(0.51)
0.10
(2.5)
Ferrite Core Chip Inductors
Dimensions:
Inches
(mm)
0.20
(0.51)
0.08
(2.03)
Terminal wrap around:
0.15 mm min. Both Ends
0.028
(0.70)
0.05
(1.27)
0.10
(2.54)
0.118
(2.99)
0.09
(2.2)
0.04
(1.02)
Allied
Part
Number
LS10-1R2J-RC
LS10-1R5J-RC
LS10-1R8J-RC
LS10-2R2J-RC
LS10-2R7J-RC
LS10-3R3J-RC
LS10-3R9J-RC
LS10-4R7J-RC
LS10-5R6J-RC
LS10-6R8J-RC
LS10-8R2J-RC
LS10-100J-RC
LS10-150J-RC
Inductance
(µh)
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.0
15.0
Tolerance
(%)
5
5
5
5
5
5
5
5
5
5
5
5
5
Q
Typ.
(L) Test
Freq.
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
SRF
Min.
(MHz)
350
300
280
250
200
200
170
130
110
105
90
85
38
DCR
Max.
(Ω)
0.50
0.65
0.75
0.90
1.00
1.15
1.25
1.35
1.45
1.60
1.80
2.40
2.40
IDC
Current
(mA)
1200
1200
1050
950
950
900
850
800
700
600
550
500
450
Features
•
1008 SMD for Auto Insertion
•
Low DCR for Low Loss Applications
•
Excellent Solderability Characteristics
•
Highly resistant to mechanical forces
•
Excellent reliabiltiy in temperature
and climate change
55
58
54
48
51
58
37
37
36
33
40
40
35
Electrical
Inductance Range:
1.2µh to 15µh
Tolerance:
5% across entire range.
Also available in 10% and 20%.
Test Frequency:
(L) entire range @
7.96Mhz @ 200mv (Q) from 1.2µh to
3.3µh @ 50Mhz, from 3.9µh to 15µh
@ 7.9Mhz
Operating Temp. Range:
-25ºC ~ 85ºC
IDC:
Inductance drop 10% Typ. from
i
l
original value with no current
Resistance to Solder Heat
Pre-Heat 150ºC, 1 minute
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp.
260ºC peak
After soldering,
for 10 sec.
Test time:
6 minutes
-6
push l0 to 2000) x 10
°C.
Test Equipment
(L/Q):
HP4286A / HP4287A /Agilent E4991A
(DCR):
Chen Hwa 502BC
(SRF):
HP8753D / Agilent E4991
(IDC):
HP4284A with HP42841A /
HP4285A with HP42841A
Physical
Packaging:
2000 pieces per 7 inch reel
Marking:
3 Dot Color Code
Available in tighter tolerances.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 12/11/08
www.alliedcomponents.com
