Multilayer Chip Inductors
Dimensions:
Inches
(mm)
0.063±0.006
(1.60±0.15)
MLC05
0.031±0.006
(0.79±0.15)
*0.047±0.006
(1.19±0.15)
0.031±0.006
(0.79±0.15)
0.012±0.008
(0.30±0.20)
0.023
(0.58)
0.031
(0.79)
0.041
(1.04)
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
Q
Min.
Test
Freq.
(MHz)
SRF
Min.
(MHz)
DCR
Max.
(Ω)
IDC
Max.
(mA)
Electrical
Q vs. Frequency Characteristics:
Measured on Impedance Analyzer
HPA4195A.
Inductance
HP4285A.
Impedance vs. Frequency Characteristics:
Measured on Impedance Analyzer
HPA4195A.
Inductance
HPA4285A.
Tolerance:
For 20% use M, 10% use K
and 5% use J as part number suffix.
Mechanical
Solderability:
90% terminal coverage.
Preheat: 120
±
20° C for 60 sec. Solder:
H63A. Solder Temp.: 230
±
5°C. Flux: rosin.
Dip time: 4
±
1 sec.
Environmental
Thermal Shock:
Inductance shall be within
±5%
of initial value. Q shall be within
±
30%
of initial value within temp. range of -40°C
to + 85°C for 30 min. each for > 100 cycles.
Humidity Resistance:
Same results as
above. Temp. 4° C. Humidity: 95% RH.
Time: 1000 hrs.
High Temp Resistance:
Same results as
above. Temp: 85° C. Time: 1000 hrs.
Low Temp Resistance:
Same results as
above. Temp: -45° C. Time: 1000 hrs.
Operating Temp.:
Storage Temp.:
-25° C to +85° C.
-40° C to +85° C.
Vs.
DC
Current
Characteristics:
Measured on LCR Meter
vs.
Te m p e r a t u r e
Characteristics:
Measured on LCR Meter
MLC05-R01M-RC
MLC05-R033M-RC
MLC05-R047M-RC
MLC05-R056M-RC
MLC05-R068M-RC
MLC05-R082M-RC
MLC05-R10M-RC
MLC05-R12M-RC
MLC05-R15M-RC
MLC05-R18M-RC
MLC05-R22M-RC
MLC05-R27M-RC
MLC05-R33M-RC
MLC05-R39M-RC
MLC05-R47M-RC
MLC05-R56M-RC
MLC05-R68M-RC
MLC05-R82M-RC
MLC05-1R0K-RC
MLC05-1R2K-RC
MLC05-1R5K-RC
MLC05-1R8K-RC
MLC05-2R2K-RC
MLC05-2R7K-RC
MLC05-3R3K-RC
MLC05-3R9K-RC
MLC05-4R7K-RC
MLC05-5R6K-RC
MLC05-6R8K-RC
MLC05-8R2K-RC
MLC05-100K-RC
MLC05-120K-RC
MLC05-150K-RC
MLC05-180K-RC
MLC05-220K-RC
MLC05-270K-RC
MLC05-300K-RC
.01
.033
.047
.056
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
15
15
15
15
15
15
25
25
25
25
25
25
25
25
25
25
25
25
35
35
35
35
35
35
35
35
35
35
35
30
30
30
20
20
20
20
20
50
50
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
4
2
2
1
1
1
1
1
300
270
260
255
250
245
240
205
180
165
150
136
125
110
105
95
85
75
65
60
55
50
45
40
38
36
33
22
20
18
17
15
14
13
11
10
9
0.20
0.20
0.30
0.30
0.30
0.30
0.50
0.50
0.60
0.60
0.80
0.80
0.85
1.00
1.35
1.50
1.70
2.10
0.60
0.80
0.80
0.95
1.10
1.30
1.50
1.70
2.10
1.55
1.70
2.10
2.55
2.60
1.70
1.80
2.10
2.70
2.90
50
50
50
50
50
50
50
50
50
50
50
50
35
35
35
35
35
35
25
25
25
25
15
15
15
15
15
5
5
5
5
3
1
1
1
1
1
Physical
Packaging:
4000 pieces per
7 inch
reel.
Available in tighter tolerances.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
www.alliedcomponents.com
