MLC10
0.079±0.008
(2.01±0.20)
Multilayer Chip Inductors
0.035±0.008
(0.89±0.20)
* 0.049±0.008
(1.25±0.20)
0.020±0.012
(0.51±0.30)
Dimensions:
Inches
(mm)
0.049±0.008
(1.25±0.20)
0.039
(0.99)
0.047
(1.19)
0.045
(1.14)
Electrical
Q vs. Frequency Characteristics:
Measured on Impedance Analyzer
HPA4195A.
I n d u c t a n c e v s . Te m p e r a t u r e
Characteristics:
Measured on LCR Meter
HP4285A.
Impedance
vs.
Frequency
Characteristics:
Measured on Impedance
Analyzer HPA4195A.
Inductance Vs. DC Current
Characteristics:
Measured on LCR Meter
HPA4285A.
Tolerance:
For 20% use M, 10% use K,
and 5% use J as part number suffix.
Mechanical
Solderability:
90% terminal coverage.
Preheat: 120
±
20°C for 60 sec. Solder:
H63A. Solder Temp.: 230
±
5° C. Flux:
rosin. Dip time: 4
±
1 sec.
Environmental
Thermal Shock:
Inductance shall be within
±5%
of initial value. Q shall be within
±
30%
of initial value within temp. range of -40°C
to + 85°C for 30 min. each for > 100 cycles.
Humidity Resistance:
Same results as
above. Temp. 4° C. Humidity: 95% RH.
Time: 1000 hrs.
High Temp Resistance:
Same results as
above. Temp: 85° C. Time: 1000 hrs.
Low Temp Resistance:
Same results as
above. Temp: -45° C. Time: 1000 hrs.
Operating Temp.:
-25° C to +85° C.
Storage Temp.:
-40° C to +85° C.
Physical
Packaging:
.022µH - 2.2µH,
4000 pieces per reel.
2.7µH - 27µH
3000 pieces per
7 inch
reel.
Allied
Part
Number
Inductance Tolerance
(%)
(
µ
h)
Q
Min.
Test
Freq.
(MHz)
SRF
Min.
(MHz)
DCR
Max.
(Ω)
IDC
Max.
(mA)
MLC10-R022M-RC
MLC10-R033M-RC
MLC10-R047M-RC
MLC10-R056M-RC
MLC10-R068M-RC
MLC10-R082M-RC
MLC10-R10M-RC
MLC10-R12M-RC
MLC10-R15M-RC
MLC10-R18M-RC
MLC10-R22M-RC
MLC10-R27M-RC
MLC10-R33M-RC
MLC10-R39M-RC
MLC10-R47M-RC
MLC10-R56M-RC
MLC10-R68M-RC
MLC10-R82M-RC
MLC10-1R0K-RC
MLC10-1R2K-RC
MLC10-1R5K-RC
MLC10-1R8K-RC
MLC10-2R2K-RC
MLC10-2R7K-RC *
MLC10-3R3K-RC *
MLC10-3R9K-RC *
MLC10-4R7K-RC *
MLC10-5R6K-RC *
MLC10-6R8K-RC *
MLC10-8R2K-RC *
MLC10-100K-RC *
MLC10-120K-RC *
MLC10-150K-RC *
MLC10-180K-RC *
MLC10-220K-RC *
MLC10-270K-RC *
.022
.033
.047
.056
.068
.082
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
20
20
20
20
20
20
25
25
25
25
25
25
25
25
25
25
25
25
45
45
45
45
45
45
45
45
45
45
45
45
45
45
30
30
30
30
50
50
50
50
50
50
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
4
2
2
1
1
1
1
320
320
320
320
280
255
235
220
200
185
170
150
145
135
125
115
105
100
75
65
60
55
50
45
41
38
35
32
29
26
24
22
19
18
16
13
0.20
0.20
0.20
0.20
0.20
0.20
0.30
0.30
0.40
0.40
0.50
0.50
0.55
0.65
0.65
0.75
0.80
1.00
0.40
0.50
0.50
0.60
0.65
0.75
0.80
0.90
1.00
0.90
1.00
1.10
1.10
1.20
0.80
0.90
1.10
1.25
300
300
300
300
300
300
250
250
250
250
250
250
250
250
250
150
150
150
50
50
50
50
30
30
30
30
30
15
15
15
15
15
5
5
5
5
*See dimensional difference.
Available in tighter tolerances.
All specifications subject to change without notice.
