Power Chip Shielded Inductors
Dimensions:
Inches
(mm)
0.260 MAX.
(6.60)
0.170
(4.32)
PCIS20
0.115 MAX.
(2.92)
1st
0.175
0.120 0.050
(4.45)
(3.05) (1.27)
MAX.
2nd
3rd
0.140
(3.56)
0.040
(1.02)
0.160
(4.06)
0.055
(1.40)
Allied
Part
Number
Inductance
(µh)
Q
Min.
Q Test
Frequency
(KHz)
DCR
Max.
(Ω)
SRF
Reference
(MHz)
Irms
(A)
Features
•
Ultraminiature size for high mounting
density.
•
Magnetically Shielded
•
Minimum power loss, can help
achieve longer battery life.
•
High energy storage and very low
DCR.
•
Designed with high heat resistant
materials for reflow operation.
• Flat top for pick and place assembly.
•
Wide inductance range.
Electrical
Inductance Range:
1.0µh to 10,000µh.
Tolerance:
±20%
over the entire
inductance range.
Test Frequency:
Inductance measured
at 100KHz, 0.1 Vrms. Q measured at
200KHz from 1.0µh to 10µh and 100KHz
from 15µh to 10,000µh.
Operating Temp.Range:
i-40°C
to +85ºC
Inductance Drop:
10% typical at rated
Isat.
Temperature
10
-6
°C.
∆
T=30ºC rise typical
t0 to 2000) x
Rise:
i
at Irms.
Physical
Marking:
Color Code using standard EIA
three dot system.
PCIS20-1R0M-RC
PCIS20-1R5M-RC
PCIS20-2R2M-RC
PCIS20-3R3M-RC
PCIS20-4R7M-RC
PCIS20-6R8M-RC
PCIS20-100M-RC
PCIS20-150M-RC
PCIS20-220M-RC
PCIS20-330M-RC
PCIS20-470M-RC
PCIS20-680M-RC
PCIS20-101M-RC
PCIS20-151M-RC
PCIS20-221M-RC
PCIS20-331M-RC
PCIS20-471M-RC
PCIS20-681M-RC
PCIS20-102M-RC
PCIS20-152M-RC
PCIS20-222M-RC
PCIS20-332M-RC
PCIS20-472M-RC
PCIS20-682M-RC
PCIS20-822M-RC
PCIS20-103M-RC
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
1500
2200
3300
4700
6800
8200
10000
30
30
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
50
50
50
50
50
50
50
200
200
200
200
200
200
200
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
.040
.045
.050
.060
.065
.070
.075
.090
0.11
0.19
0.23
0.29
0.48
0.59
0.77
1.40
1.80
2.20
3.40
4.20
8.50
11.0
13.9
25.0
30.5
32.8
200
100
90
90
80
40
30
25
20
15
15
10
8.0
7.0
4.0
4.0
3.0
2.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.4
3.0
2.8
1.8
1.6
1.4
1.2
1.0
.80
.70
.60
.50
.40
.30
.26
.22
.20
.19
.18
.15
1.0
1.0
.08
.06
.04
.02
Packaging:
2500 pieces per 13 inch reel.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 02/06/09
www.alliedcomponents.com
