R1380 Series, R3390 Series
XO –
3.3V
HCMOS/TTL
Features
500KHz to 165MHz Frequency range, fixed
output
Stability options of ±100ppm to ±20ppm
Start up time is less than 5ms
Tristate
Jitter 6ps RMS
RoHS Status
Applications
DSL
Gigabit Ethernet
Fibre Channel
VoIP
Electrical Specifications
Parameter
Frequency
Range
Frequency
Stability
Operating
Temperature
Aging
Supply
Voltage
Jitter
“0” Level, sinking 16 mA
“1” Level
CMOS, sourcing 8 mA
CMOS, @ 50% V
DD
CMOS, 15 pF
CMOS, 30 pF
CMOS, 50 pF
CMOS, 15 pF
CMOS, 30 pF
Vcc
Symbol
F
∆F/F
T
First Year
After First Year
3.0
Operating Temperature at
25°C
Condition
Min
0.5
±
20
0°
3
1
3.3
3.6
6
0.4
V
V
DD
-0.4
48/52
3.0
4.0
6.0
2.0
3.0
45/55
4
5
8
2.5
4.5
%
20 to 80% (<60 MHz)
ns
20 to 80% (>60 MHz)
Typ
Max
165
±100
+70°
Unit
MHz
ppm
°C
ppm
ppm/yr
V
ps RMS
See Chart
Note
Output Levels
Symmetry
Rise and Fall
Times
75 South Street, Hopkinton, MA 01748 • 800-982-5737 • 508-435-6831 • FAX 508-435-5289
www.valpeyfisher.com
RevB0209
1
R1380 Series, R3390 Series
XO –
3.3V
HCMOS/TTL
Electrical Specifications
Parameter
Symbol
Condition
3 to 10 MHz
10.1 to 20 MHz
20.1 to 30 MHz
30.1 to 50 MHz
50.1 to 67 MHz
67.1 to 125 MHz
Min
Typ
3.0
5.0
10.0
35.0
40.0
60.0
Max
4.5
6.0
15.0
40.0
50.0
70.0
Unit
Note
Supply
Current
Icc
mA
Input
Requirements
for Pin 1
“1”: On – Pin 1 may float or 2.4V min., sourcing 400 µA
“0”: Disable or Tristate – Pin 1 requires 0.4V, sinking 400 µA
“0” Level, sinking 16 mA
“1” Level
CMOS, sourcing 8 mA
0.4
V
V
DD
-0.4
Output Levels
Environmental and Mechanical Conditions
Parameter
Shock
Vibration
Humidity
Leak
Pads
Case
Marking
Resistance to Solvents
Specification
1000 Gs, 0.35 ms, 1/2 sine wave, 3 shocks in each plane
10-2000 Hz of .06" d.a. or 20 Gs, whichever is less
Resistant to 85° R.H. at 85°C
MIL STD 883, Method 1014, condition A1
0.3 - 1um gold over Ni ( 10 to 40 µinches of gold )
Over 1.27 - 8.89um Ni ( 50 to 350 µinches of Ni )
Ceramic with hermetic resistance-welded metal lid
Epoxy ink or laser engraved
MIL STD 202, Method 215
Marking Specifications
FIXED OUTPUT
Model
R1380
R1381
R1382
R1388
R1389
Marking Code ID*
E
AL
F
BV
BW
Model
R3390
R3391
R3392
R3398
R3399
TRISTATE
Marking Code ID*
G
Q
H
BY
BZ
Frequency
Stability
±100 ppm
±25 ppm
±50 ppm
±20 ppm
±32 ppm
*See Marking Specification
75 South Street, Hopkinton, MA 01748 • 800-982-5737 • 508-435-6831 • FAX 508-435-5289
www.valpeyfisher.com
RevB0209
2
R1380 Series, R3390 Series
XO –
3.3V
HCMOS/TTL
Recommended Reflow Soldering Profile
Waveforms
HOW TO ORDER
R
-
3
3 9 0
“3390” is
model type
-
FREQ.
“R” is SMD model
Fig.1 R3392-20M with 25pf load
Fig.2 R3392-20M without load
75 South Street, Hopkinton, MA 01748 • 800-982-5737 • 508-435-6831 • FAX 508-435-5289
www.valpeyfisher.com
RevB0209
3
R1380 Series, R3390 Series
XO –
3.3V
HCMOS/TTL
Test Circuit
Fixed Output
Models
Pad 1
Pad 2
Pad 3
Pad 4
NOT USED
Tristate Models
Floating or 1 : Oscillator runs
Ground or 0 : Disable or Tristate
Ground and Case
Output
+3.3V, V
DD
75 South Street, Hopkinton, MA 01748 • 800-982-5737 • 508-435-6831 • FAX 508-435-5289
www.valpeyfisher.com
RevB0209
4
