This product complies with the RoHS Directive (EU 2002/95/EC).
Infrared Light Emitting Diodes
LNA2903L
(LN66A)
GaAs Infrared Light Emitting Diode
For remote control systems
Features
High-power output, high-efficiency: I
e
= 9 mW/sr (min.)
Emitted light spectrum suited for silicon photodetectors
Good radiant power output linearity with respect to input current
Wide directivity:
θ
= 20° (typ.)
Transparent epoxy resin package
Absolute Maximum Ratings
T
a
= 25°C
Parameter
Power dissipation
Forward current
Pulse forward current
*
Reverse voltage
Operating ambient temperature
Storage temperature
Note) *: f = 100 Hz, Duty cycle = 0.1%
Symbol
P
D
I
F
I
FP
V
R
T
opr
T
stg
Rating
160
100
1.5
3
–25 to +85
–40 to +100
Unit
mW
mA
A
V
°C
°C
Electrical-Optical Characteristics
T
a
= 25°C±3°C
Parameter
Radiant power
Reverse current
Forward voltage
Pulse forward voltage
*1
Center radiant intensity
*2
Terminal capacitance
Peak emission wavelength
Spectral half band width
Half-power angle
2. Cutoff frequency: 1 MHz
f
C
: 10
×
log
P
O
at f = f
C
P
O
at f = 50 kHz
=
−3
Symbol
P
O
I
R
V
F
V
FP
I
e
C
t
λ
P
Δλ
θ
I
F
= 50 mA
V
R
= 3 V
I
F
= 100 mA
I
FP
= 1.0 A
I
F
= 50 mA
Conditions
Min
Typ
12.0
Max
10
Unit
mW
µA
V
V
mW/sr
pF
nm
nm
°
1.4
9.0
35
950
50
20
1.6
3.0
V
R
= 0 V, f = 1 MHz
I
F
= 50 mA
I
F
= 50 mA
The angle when the radiant power is halved.
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
3. *1: f = 100 Hz, Duty cycle = 0.1%
*2: Rank classification
Rank
I
e
(mW/sr)
No-rank
9.0
≤
S
11.0
≤
Note) The part number in the parenthesis shows conventional part number.
Publication date: October 2008
SHC00032CED
1
Request for your special attention and precautions in using the technical information and
semiconductors described in this book
(1)
If any of the products or technical information described in this book is to be exported or provided to non-residents, the laws and
regulations of the exporting country, especially, those with regard to security export control, must be observed.
(2) The technical information described in this book is intended only to show the main characteristics and application circuit examples
of the products. No license is granted in and to any intellectual property right or other right owned by Panasonic Corporation or any
other company. Therefore, no responsibility is assumed by our company as to the infringement upon any such right owned by any
other company which may arise as a result of the use of technical information described in this book.
(3) The products described in this book are intended to be used for standard applications or general electronic equipment (such as office
equipment, communications equipment, measuring instruments and household appliances).
Consult our sales staff in advance for information on the following applications:
–
Special applications (such as for airplanes, aerospace, automobiles, traffic control equipment, combustion equipment, life support
systems and safety devices) in which exceptional quality and reliability are required, or if the failure or malfunction of the prod-
ucts may directly jeopardize life or harm the human body.
–
Any applications other than the standard applications intended.
(4) The products and product specifications described in this book are subject to change without notice for modification and/or im-
provement. At the final stage of your design, purchasing, or use of the products, therefore, ask for the most up-to-date Product
Standards in advance to make sure that the latest specifications satisfy your requirements.
(5) When designing your equipment, comply with the range of absolute maximum rating and the guaranteed operating conditions
(operating power supply voltage and operating environment etc.). Especially, please be careful not to exceed the range of absolute
maximum rating on the transient state, such as power-on, power-off and mode-switching. Otherwise, we will not be liable for any
defect which may arise later in your equipment.
Even when the products are used within the guaranteed values, take into the consideration of incidence of break down and failure
mode, possible to occur to semiconductor products. Measures on the systems such as redundant design, arresting the spread of fire
or preventing glitch are recommended in order to prevent physical injury, fire, social damages, for example, by using the products.
(6) Comply with the instructions for use in order to prevent breakdown and characteristics change due to external factors (ESD, EOS,
thermal stress and mechanical stress) at the time of handling, mounting or at customer's process. When using products for which
damp-proof packing is required, satisfy the conditions, such as shelf life and the elapsed time since first opening the packages.
(7) This book may be not reprinted or reproduced whether wholly or partially, without the prior written permission of our company.
20080805
