Power Chip Shielded Inductors
Inches
(mm)
PCSDR125
Dimensions:
8
8
Allied
Part
Number
Inductance
Tolerance
(µh)
(%)
Test
Freq.
KHz, 0.1V
DCR
(Ω)
I rms
(A)
I sat
(A)
Features
• Magnetically Shielded
• High saturation current
•
•
•
•
•
Expanded operating temp range
Low DC Resistance
High Energy Storage
Low Energy Loss
Suitable for pick and place
Electrical
Inductance Range:
.47µh to 1200µh
Tolerance:
.47µh~6.8µh 30%,
8.2µh~1200µh 20%
Available in tighter tolerances
Test Frequency:
100KHz, 0.1V
Operating Temp:
-55ºC ~ +125ºC
Irms:
Current at which the
∆
T=40ºC
Isat:
Current at which the inductance
drops 35% from initial value
PCSDR125-R47T-RC
PCSDR125-R82T-RC
PCSDR125-1R5T-RC
PCSDR125-2R2T-RC
PCSDR125-3R3T-RC
PCSDR125-3R9T-RC
PCSDR125-4R7T-RC
PCSDR125-6R8T-RC
PCSDR125-8R2M-RC
PCSDR125-100M-RC
PCSDR125-120M-RC
PCSDR125-150M-RC
PCSDR125-180M-RC
PCSDR125-220M-RC
PCSDR125-270M-RC
PCSDR125-330M-RC
PCSDR125-390M-RC
PCSDR125-470M-RC
PCSDR125-560M-RC
PCSDR125-680M-RC
PCSDR125-820M-RC
PCSDR125-101M-RC
PCSDR125-121M-RC
PCSDR125-151M-RC
PCSDR125-181M-RC
PCSDR125-221M-RC
PCSDR125-271M-RC
PCSDR125-331M-RC
PCSDR125-391M-RC
PCSDR125-471M-RC
PCSDR125-561M-RC
PCSDR125-681M-RC
PCSDR125-821M-RC
PCSDR125-102M-RC
PCSDR125-122M-RC
0.47
0.82
1.5
2.2
3.3
3.9
4.7
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
30
30
30
30
30
30
30
30
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
0.0022
0.0029
0.0035
0.0054
0.0076
0.0099
0.0126
0.0148
0.0200
0.0227
0.0250
0.0334
0.0373
0.0475
0.0594
0.0606
0.0767
0.0888
0.1062
0.1282
0.1700
0.2040
0.2350
0.3350
0.3630
0.4920
0.5700
0.6500
0.7200
0.9820
1.1300
1.3200
1.7880
2.0280
2.3300
17.401
15.069
13.709
11.005
9.301
7.346
7.204
6.656
5.565
5.370
4.736
4.277
3.896
3.710
3.318
3.285
2.920
2.714
2.482
2.323
2.063
1.790
1.668
1.482
1.341
1.191
1.091
1.063
0.969
0.871
0.778
0.704
0.605
0.568
0.530
32.960
23.540
18.310
14.980
12.680
10.990
9.690
8.670
7.850
7.170
6.590
5.680
5.320
4.710
4.230
3.830
3.510
3.230
2.890
2.620
2.460
2.200
2.030
1.810
1.660
1.510
1.340
1.200
1.110
1.010
0.910
0.850
0.770
0.700
0.630
Resistance to Soldering Heat
Pre-Heat 150ºC, 1 Min.
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
260ºC +/- 5ºC
Immersion time:
10 sec. +/- 1 sec.
Test Equipment
(L):
HP 4284A LCR meter or equivalent
(RDC):
HP 4338B Millohm meter or equivalent
(IDC):
3260B WK & DC Bias 3265B WK
Physical
Packaging:
600 pieces per 13 inch reel.
Marking:
EIA Inductance Code.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 8/7/09
15
www.alliedcomponents.com
