ADCLK954BCPZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> ADCLK954BCPZ

ADCLK954BCPZ: Description954 SERIES, LOW SKEW CLOCK DRIVER, 12 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), QCC40, 6 X 6 MM, ROHS COMPLIANT, MO-220VJJD-2, LFCSP-40; Categorylogic logic; File Size1MB，13 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

ADCLK954BCPZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ADCLK954BCPZ	-	-	View	Buy Now

ADCLK954BCPZ Overview

954 SERIES, LOW SKEW CLOCK DRIVER, 12 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), QCC40, 6 X 6 MM, ROHS COMPLIANT, MO-220VJJD-2, LFCSP-40

ADCLK954BCPZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	QFN
package instruction	HVQCCN,
Contacts	40
Reach Compliance Code	unknown
series	954
Input adjustment	DIFFERENTIAL
JESD-30 code	S-XQCC-N40
JESD-609 code	e3
length	6 mm
Logic integrated circuit type	LOW SKEW CLOCK DRIVER
Humidity sensitivity level	NOT APPLICABLE
Number of functions	1
Number of inverted outputs
Number of terminals	40
Actual output times	12
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	UNSPECIFIED
encapsulated code	HVQCCN
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	260
propagation delay (tpd)	0.21 ns
Certification status	COMMERCIAL
Maximum seat height	1 mm
Maximum supply voltage (Vsup)	3.63 V
Minimum supply voltage (Vsup)	2.97 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	40
width	6 mm
minfmax	4500 MHz
Base Number Matches	1
