Radial Bobbin Inductors
Dimensions:
Inches
(mm)
RB40
0.315 MAX.
(8.00)
0.441
(11.20)
MAX.
0.315 MAX.
(8.00)
0.197±0.1
(5.00±1.02)
0.197±0.10
(5.00±2.54)
22 AWG
Allied
Part
Number
Inductance Tolerance
(µh)
(%)
Q
Min.
Test
Freq.
(MHz)
SRF
Min.
(MHz)
DCR
Max.
(Ω)
Rated
Current
(mA)
Features
RB40-101K-RC
RB40-121K-RC
RB40-151K-RC
RB40-181K-RC
RB40-221K-RC
RB40-271K-RC
RB40-331K-RC
RB40-391K-RC
RB40-471K-RC
RB40-561K-RC
RB40-681K-RC
RB40-821K-RC
RB40-102K-RC
RB40-122K-RC
RB40-152K-RC
RB40-182K-RC
RB40-222K-RC
RB40-272K-RC
RB40-332K-RC
RB40-392K-RC
RB40-472K-RC
RB40-562K-RC
RB40-682K-RC
RB40-822K-RC
RB40-103K-RC
RB40-123K-RC
RB40-153K-RC
RB40-183K-RC
RB40-223K-RC
RB40-273K-RC
RB40-333K-RC
RB40-363K-RC
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
36000
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
80
80
80
80
80
80
80
80
80
80
80
80
90
90
90
90
90
90
90
90
90
90
90
90
100
100
100
100
100
100
100
100
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.252
0.0796
0.0796
0.0796
0.0796
0.0796
0.0796
0.0796
0.0796
5.3
4.5
3.8
3.3
2.9
2.6
2.3
2.1
1.9
1.7
1.6
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0.7
0.6
0.6
0.5
0.5
0.4
0.4
0.4
0.3
0.3
0.3
0.3
0.3
2.0
2.0
2.0
3.0
3.0
3.0
4.0
4.0
4.0
4.0
4.0
6.0
6.0
9.0
9.0
9.0
13.0
13.0
13.0
13.0
18.0
18.0
26.0
26.0
40.0
40.0
60.0
60.0
80.0
80.0
80.0
80.0
200
200
200
200
200
200
200
200
200
200
200
200
150
150
150
100
100
100
100
50
50
50
50
50
40
40
40
30
30
30
30
30
•
•
•
Radial leaded pre-tinned leads.
Protected with UL Polyolefin shrink
tubing.
Non-standard values and tolerances
available.
Electrical
Inductance Range:
36000µh.
100µh to
Tolerance:
10% over entire inductance
range. Tighter tolerances available.
Test Procedures:
L&Q Measured with
HP4342A Q-Meter at specified Frequency.
DCR Measured on CH-301, SRF
Measured on HP-4191A, HP4291B.
Operating Temp:
-55º C to +125º C.
Current Rating:
Based on Inductance
Drop of <10% at rated current.
Physical
Marking (on Part):
EIA Code
Marking (on Reel):
Manufacturers
Name, Part Number, Customers
Part Number, Invoice Number, Lot
or Data Code.
All specifications subject to change without notice.
Packaging:
100 pieces per bag.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 08/09/08
www.alliedcomponents.com
