Document 228-1
DO1608 Inductors for xDSL Filters
These low cost, high inductance inductors are ideal
for use in a variety of filters, including the data separation
filters used in ADSL, VDSL and ISDN/ADSL implemen-
tations.
Their wirewound design and ferrite core provide high Q
factors, low DCR and high current handling.
Coilcraft offers a library of reference designs for various
xDSL filters using these and other surface mount compo-
nents. We can also provide several complete low pass
and band pass filter modules in space-saving SIP con-
figurations.
0.260 max
6,60
Part
number
0.050
1,27
0.090
2,29
0.055
1,40
0.160
4,06
0.140
3,56
L
±
20%
1
DCR max SRF typ
Isat
2
Irms
3
(µH)
(Ohms)
(MHz)
(A)
(A)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
0.05
0.05
0.07
0.08
0.09
0.13
0.16
0.23
0.37
0.51
0.64
0.86
1.27
2.00
3.11
3.80
5.06
9.20
13.8
130
115
90
70
50
45
35
30
20
15
14
11
9
6
5.5
5
4
3
2
2.90
2.60
2.30
2.00
1.50
1.20
1.10
0.90
0.70
0.58
0.50
0.40
0.31
0.27
0.22
0.18
0.16
0.14
0.10
2.9
2.8
2.4
2.0
1.5
1.4
1.1
1.2
0.8
0.6
0.5
0.4
0.3
0.25
0.2
0.16
0.15
0.12
0.07
0.175 max
4,45
0.170 min
4,32
0.040
1,02
0.270
6,86
0.155
3,94 dia
0.115
max
2,92
Recommended
Land Pattern
Part Markings
Dash
number
1st
significant
digit
2nd
significant
digit
DO1608C-102
DO1608C-152
DO1608C-222
DO1608C-332
DO1608C-472
DO1608C-682
DO1608C-103
DO1608C-153
DO1608C-223
DO1608C-333
DO1608C-473
DO1608C-683
DO1608C-104
DO1608C-154
DO1608C-224
DO1608C-334
DO1608C-474
DO1608C-684
DO1608C-105
Tape and reel:
750/7″ reel; 2500/13″ reel 12 mm tape width
For packaging data see Tape and Reel Specifications section.
XXX
XXX
Multiplier
1. Tested at 100 kHz, 0.1 Vrms, 0 Adc.
2. DC current at which the inductance drops 10% (typ) from its value
without current.
3. Average current for 15°C temperature rise from 25°C.
4. Operating temperature range
−40°C
to +85°C.
5. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
See Color Coding section for part marking data.
Specifications subject to change without notice.
Document 228-1
Revised 10/29/02
© Coilcraft, Inc. 2005
