RoHS
Toroidal Chokes High Temp
TC210HT
0.45
MAX
(11.43)
0.86
MAX
(21.84)
Dimensions:
Inches
(mm)
Tin lead to coil
0.50
(12.70)
C
A
B
Vertical Mount
Horizontal Mount
Allied
Part
Number
Inductance Tolerance
(µH)
(%)
@ 1KHZ
L(µH)
@
I rated
IDC
(A)
DCR
(Ω)
MAX
DIM
DIM
DIM
B
C
A
(Nom) (Nom) (Nom)
Features
•
•
•
•
•
•
High Temperature rating up to 200ºC
Low Magnetic Radiation
Low Core Loss
High current capacity up to 21A
Available in Horizontal or Vertical configuration
Optional Tape Cover
Electrical
Inductance Range:
1.0µh to 1000µh
Additional values available
Tolerance:
15% over entire range
Test Frequency:
1KHz
Operating Temp:
-55ºC ~ +200ºC
Temp Rise:
∆
T=30ºC Typical at rated IDC
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
(
)TC210HT-1R0L-RC
)TC210HT-1R5L-RC
)TC210HT-2R2L-RC
)TC210HT-2R7L-RC
)TC210HT-3R3L-RC
)TC210HT-3R9L-RC
)TC210HT-4R7L-RC
)TC210HT-5R6L-RC
)TC210HT-6R8L-RC
)TC210HT-8R2L-RC
)TC210HT-100L-RC
)TC210HT-120L-RC
)TC210HT-150L-RC
)TC210HT-180L-RC
)TC210HT-220L-RC
)TC210HT-270L-RC
)TC210HT-330L-RC
)TC210HT-390L-RC
)TC210HT-470L-RC
)TC210HT-560L-RC
)TC210HT-680L-RC
)TC210HT-820L-RC
)TC210HT-101L-RC
)TC210HT-121L-RC
)TC210HT-151L-RC
)TC210HT-181L-RC
)TC210HT-221L-RC
)TC210HT-271L-RC
)TC210HT-331L-RC
)TC210HT-391L-RC
)TC210HT-471L-RC
)TC210HT-561L-RC
)TC210HT-680L-RC
)TC210HT-821L-RC
)TC210HT-102L-RC
1.0
1.5
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
0.8
1.2
1.8
2.1
2.6
3.0
3.5
4.1
4.9
5.9
7.6
9.0
11.0
13.0
16.6
20.1
24.0
28.0
33.1
38.5
46.0
54.0
64.5
84.4
102.8
120.7
144.2
172.6
206.0
266.7
314.4
366.9
435.1
512.0
608.2
21.7
19.8
18.3
17.1
16.1
15.3
14.9
14.3
13.7
13.2
9.9
9.6
9.1
8.6
6.7
6.4
6.1
5.9
5.6
5.3
5.1
4.8
4.6
3.5
3.3
3.1
3.0
2.8
2.7
2.1
2.0
1.9
1.8
1.7
1.6
.003
.003
.004
.004
.005
.005
.006
.006
.006
.007
.012
.013
.014
.016
.026
.028
.031
.033
.036
.040
.044
.049
.053
.094
.110
.120
.130
.140
.160
.270
.290
.320
.350
.390
.430
.34
.34
.34
.34
.34
.34
.34
.34
.34
.34
.33
.33
.33
.33
.32
.32
.35
.35
.35
.35
.35
.35
.35
.34
.34
.34
.35
.35
.35
.33
.35
.35
.35
.37
.37
.77
.77
.77
.77
.77
.77
.77
.77
.77
.77
.76
.76
.76
.76
.75
.75
.79
.79
.79
.79
.79
.79
.79
.77
.77
.77
.79
.79
.79
.76
.79
.79
.79
.81
.81
.053
.053
.053
.053
.053
.053
.053
.053
.053
.053
.042
.042
.042
.042
.034
.034
.034
.034
.034
.034
.034
.034
.034
.027
.027
.027
.027
.027
.027
.022
.022
.022
.022
.022
.022
Test Equipment
(L):
100 LCR meter or equivalent
DCR:
Chen Hwa 502
Physical
Packaging:
Bulk
Marking:
None
Please specify Vertical or Horizontal Mount
by placing a V or H at the beginning of the part number,
i.e. VTC210HT-100L (Vertical Mount). All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 8/10/09
www.alliedcomponents.com
