PR33MF51NSZF Series
PR39MF51NSLF
PR39MF51NSLF
PR33MF51NSZF
Series
I
T
(rms)≤0.3A, Non-Zero Cross type
0.9A,
DIP 8pin
Triac output SSR
■
Description
PR39MF51NSLF
PR33MF51NSZF Series
Solid State Relays (SSR)
are an integration of an infrared emitting diode (IRED),
a Phototriac Detector and a main output Triac. These
devices are ideally suited for controlling high voltage AC
loads with solid state reliability while providing 4kV isola-
tion (V
iso
(rms)) from input to output.
■
Agency approvals/Compliance
1. Recognized by UL508 file No. E94758 (as model No.
R33MF5)
R39MF5
)
2. Approved by CSA 22.2 No.14, file No. LR63705 (as
R39MF5
)
model No.
R33MF5)
3. Optionary available VDE approved (DIN EN 60747-5-
R39MF5
)
2)
(
∗
)
, file No. 40008898 (as model No.
R33MF5)
4. Package resin : UL flammability grade (94V-0)
(
∗
)
■
Features
1. Output current, I
T
(rms)≤0.3A
0.9A
2. Non-zero crossing functionary
3. 8 pin DIP package (SMT gullwing also available)
4. High repetitive peak off-state voltage (V
DRM
: 600V)
5. Superior noise immunity (dV/dt : MIN. 100V/μs)
6. Response time, t
on
: MAX. 100μs
7. High isolation voltage between input and output
(V
iso
(rms) : 4kV)
8. RoHS directive compliant
DIN EN60747-5-2 : successor standard of DIN VDE0884.
■
Applications
1. Isolated interface between high voltage AC devices
and lower voltage DC control circuitry.
2. Switching motors, fans, heaters, solenoids, and
valves.
3. Phase or power control in applications such as light-
ing and temperature control equipment.
Notice The content of data sheet is subject to change without prior notice.
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
1
Sheet No.: D4-A03901FEN
Sheet No.:OP13011EN
Date Sep. 1. 2006
© SHARP Corporation
PR33MF51NSZF Series
PR39MF51NSLF
■
Internal Connection Diagram
8
6
5
1
2
3
4
Cathode
Anode
Cathode
Cathode
5
6
8
Gate
Output (T
1
)
Output (T
2
)
1
2
3
4
■
Outline Dimensions
1. Through-Hole [ex.
PR39MF51NSLF]
[ex.
PR33MF51NSZF]
1.2
±
0.3
SHARP
mark
"S"
8
6
(Unit : mm)
PR39MF51NPLF]
2. SMT Gullwing Lead-Form
[ex.
PR33MF51NIPF]
1.2
±
0.3
SHARP
mark
"S"
8
6
1.05
5
±
0.20
1.05
±
0.20
5
Model No.
6.5
±
0.5
Model No.
R33MF5
9
CSA mark
1
2
3
4
Rank mark
CSA mark
Date code (2 digit)
Factory identification mark
7.62
±
0.30
0.5
TYP.
3.5
±
0.5
1
2
3
4
6.5
±0.5
Rank mark
R33MF5
9
Anode
mark
9.66
±
0.50
Anode
mark
Date code (2 digit)
Factory identification mark
0.35
±0.25
1.0
+0.4
−0
0.35
±0.25
1.0
+0.4
−0
9.66
±
0.50
0.26
±0.10
7.62
±0.30
3.25
±
0.50
3.5
±0.5
Epoxy resin
0.26
±
0.10
θ
θ
:
0 to 13
˚
θ
2.54
±0.25
2.54
±
0.25
0.5
±
0.1
1.0
+0.4
−0
Epoxy resin
10.0
+0
−0.5
Product mass : approx. 0.56g
Product mass : approx. 0.54g
3. Through-Hole VDE option
[ex.
PR39MF51YSLF]
[ex.
PR33MF51YSZF]
1.2
±0.3
SHARP
mark
"S"
8
6
4. SMT Gullwing Lead-Form VDE option
[ex.
PR33MF51YIPF]
[ex.
PR39MF51YPLF]
1.2
±
0.3
SHARP
mark
"S"
8
6
1.05
±0.20
5
1.05
±
0.20
5
Model No.
6.5
±0.5
Model No.
4
CSA mark
1
2
3
4
4
Rank mark
CSA mark
VDE identification mark
1
2
3
4
6.5
±0.5
Rank mark
VDE identification mark
R33MF5
9
R33MF
5
9
Anode
mark
9.66
±0.50
Date code (2 digit)
Factory identification mark
7.62
±0.30
0.5
TYP.
3.5
±0.5
Anode
mark
9.66
±
0.50
Date code (2 digit)
Factory identification mark
7.62
±0.30
0.26
±0.10
3.5
±0.5
3.25
±0.50
Epoxy resin
0.26
±0.10
θ
θ
:
0 to 13
˚
θ
2.54
±0.25
2.54
±0.25
0.5
±0.1
1.0
+0.4
−0
Epoxy resin
10.0
+0
−0.5
Product mass : approx. 0.56g
Product mass : approx. 0.54g
Plating material : SnCu (Cu : TYP. 2%)
Sheet No.: D4-A03901FEN
Sheet No.:OP13011EN
2
PR33MF51NSZF Series
PR39MF51NSLF
Date code (2 digit)
1st digit
Year of production
Mark
A.D.
A
2002
B
2003
C
2004
D
2005
E
2006
F
2007
H
2008
J
2009
K
2010
L
2011
M
2012
N
:
2nd digit
Month of production
Month
Mark
January
1
February
2
March
3
April
4
May
5
June
6
July
7
August
8
September
9
October
O
November
N
December
D
A.D.
1990
1991
1992
1993
1994
1995
1996
1997
1998
1999
2000
2001
Mark
P
R
S
T
U
V
W
X
A
B
C
:
repeats in a 20 year cycle
Factory identification mark
Factory identification Mark
no mark
Country of origin
Japan
Japan
China
* This factory marking is for identification purpose only.
Please contact the local SHARP sales representative to see the actural status of the
production.
Rank mark
Please refer to the Model Line-up table.
Sheet No.: D4-A03901FEN
Sheet No.:OP13011EN
3
PR33MF51NSZF Series
PR39MF51NSLF
■
Absolute Maximum Ratings
Parameter
Forward current
Input
Reverse voltage
RMS ON-state current
Output
Peak one cycle surge current
Repetitive peak OFF-state voltage
*1
Isolation voltage
Operating temperature
Storage temperature
*2
Soldering temperature
*1 40 to 60%RH, AC for 1minute, f=60Hz
*2 For 10s
*3 Refer to Fig.1, Fig.2
*4 f=50Hz sine wave
(T
a
=
25˚C)
Symbol
Rating
Unit
∗3
I
F
50
mA
V
R
6
V
3
I
T
(rms)
0.3
*
A
0.9
∗3
∗4
I
surge
3
A
9
V
DRM
600
V
V
iso
(rms)
4
kV
T
opr
˚C
−
30 to
+
85
T
stg
˚C
−
40 to
+
125
T
sol
270
˚C
Soldering area
■
Electro-optical Characteristics
Parameter
Forward voltage
Input
Reverse current
Repentitive peak OFF-state current
ON-state voltage
Output
Holding current
Critical rate of rise of OFF-state voltage
Transfer Minimum trigger current
charac- Isolation resistance
teristics Turn-on time
Symbol
V
F
I
R
I
DRM
V
T
I
H
dV/dt
I
FT
R
ISO
t
ON
Condition
I
F
=
20mA
V
R
=
3V
V
D
=
V
DRM
I
T
=
0.3A
0.9A
V
D
=
6V
−
V
D
=
1/
√
2 ·V
DRM
V
D
=
6V, R
L
=
100
Ω
DC500V, 40 to 60%RH
V
D
=
6V, R
L
=
100
Ω
, I
F
=
20mA
MIN.
−
−
−
−
−
100
−
5
×
10
10
−
TYP.
1.2
−
−
−
−
−
−
10
11
−
MAX.
1.4
10
100
3
25
−
10
−
100
1mm
(T
a
=
25˚C)
Unit
V
μ
A
μ
A
V
mA
V/
μ
s
mA
Ω
μ
s
Sheet No.: D4-A03901FEN
Sheet No.:OP13011EN
4
