MULTILAYER CERAMIC CAPACITORS
METAL CAP TYPE MULTILAYER CERAMIC CAPACITORS
/
?FEATURES
(High Reliability)
1. Small mounting area.
2. Small in size and large capacitance. (maximum 200MF)
3. High rated ripple current.
4. Excellent temperature cycle durability and most suitable for aluminum substrate.
5. Y5U temperature characteristics.
6. Excellent high frequency characterisitics.
7. 200V
dc
items are available.
8. For reflow soldering use.
?APPLICATIONS
1. Smoothing circuit of switching mode AC-DC or DC-DC converter.
2. On-board power supply.
3. Noise suppressor for various kinds of equipments.
?CUSTOM
MADE PRODUCTS
We can offer custom made one element metal cap type capacitors for request of customers.
Please contact us if you have questions for details.
?CONSTRUCTION
Chip Ceramic Capacitor
Metal Cap
Soldering
Termination
?RATINGS
1.
2.
3.
4.
5.
6.
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Rated Capacitance Tolerance
Temperature Characteristics
Rated Ripple Current
-55K+125C
16, 25, 50, 100, 200V
dc
0.45 to 200MF
M(P20%), Z(P
80
%)
20
E(JIS) Y5U(EIA)
See No.5 on the following table
?SPECIFICATIONS
No.
1
2
Items
Withstand Voltage
Insulation Resistance
Specification
No abnormality.
1000/C
R
(MO) or 10000(MO) whichever
is less.
Within specified tolerance.
Test Condition
250% of rated voltage shall be applied for 5 seconds.
Rated voltage shall be applied for 60P5 seconds at
temperature 20P2C.
Temperature
Frequency
Voltage
Temperature
Frequency
Voltage
55
3.0
76
4.0
: 20P2C
: 1P0.1kHz (]100MF, 120Hz)
: 1P0.2Vrms
: 20P2C
: 1P0.1kHz (]100MF, 120Hz)
: 1P0.2Vrms
3
Rated Capacitance
4
Dissipation Factor
5.0% maximum
5
Rated Ripple Current
Size
Arms
43
1.5
10kHzK1MHz (sine curve)
Ripple voltage Vp shall be less than
the rated voltage.
(1/4)
CAT. No. E1002K
MULTILAYER CERAMIC CAPACITORS
METAL CAP TYPE MULTILAYER CERAMIC CAPACITORS
/
?SPECIFICATIONS
No.
6
Items
Temperature Cycle
Specification
Appearance : No visible damage.
DC/C
:
P15%
D.F. : To meet the initial specification.
I.R. : To meet the initial specification.
Test Condition
Step
Temperature (C)
1
Min. Category temperature
P3
2
Room temperature
3
Max. Category temperature
P2
4
Room temperature
<Cycle>
THP series : 100 cycles
TMP series : 500 cycles
Temperature : 40P2C
Humidity
: 90 to 95%RH
Voltage
: Rated voltage
Time
: 500P
24
hours
0
Temperature : 85P2C
Voltage
: 200% of rated voltage.
Time
: 1000P
48
hours
0
Temperature : 125P3C
Voltage
: Rated voltage
Time
: 1000P
48
hours
0
(min.)
30P3
3 max.
30P3
3 max.
7
Humidity Load Life
Appearance : No abnormality.
DC/C
:
P20%
D.F. : 7% max.
I.R. : 50/C
R
(MO) or 1000(MO)
whichever is less.
Appearance : No abnormality.
DC/C
:
P20%
D.F. : 7% max.
I.R. : 100/C
R
(MO) or 1000(MO)
whichever is less.
8
Endurance
*C
R
: Rated Capacitance(MF)
?Note
of mountig for THP series.
1. The face of wider gap between a capacitor and a substrate shall be the mounting face.
2. To prevent degredation of heat cycling capability, if need to be careful about amount of solder that would not go into
the inner side of terminations.
Substrate
Gap
?Note:
Single capacitor with metal cap and the silver plating cap (RoHS Compliant) is available upon request.
Please consult us for details.
(2/4)
CAT. No. E1002K
MULTILAYER CERAMIC CAPACITORS
METAL CAP TYPE MULTILAYER CERAMIC CAPACITORS
?PART
NUMBERING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
?DIMENSIONS
43, 55 size
T
T
K HP 2 5 0 E 4 7 6 M 5 5 2A T 0 0
Supplement code
Taping code
Terminal code
Size code
Capacitance tolerance code
Nominal Capacitance code
Temperature characteristics code
Rated voltage code
Series code
Category
76 size
L
L
W
a
W
a
?THP
SERIES STANDARD RATINGS
Part Number
KHP160E336M432AT00
KHP160E476M432AT00
KHP160E686M552AT00
KHP160E107M552AT00
KHP160E157M762BT00
KHP160E207M762BT00
KHP250E156M432AT00
KHP250E206M432AT00
KHP250E336M552AT00
KHP250E476M552AT00
KHP250E686M552AT00
KHP250E107M762BT00
KHP500E455M432AT00
KHP500E685M432AT00
KHP500E106M552AT00
KHP500E156M552AT00
KHP500E226M552AT00
KHP500E336M762BT00
KHP500E476M762BT00
KHP101E155M432AT00
KHP101E205M432AT00
KHP101E305M432AT00
KHP101E475M552AT00
KHP101E685M552AT00
KHP101E106M552AT00
KHP101E156M762BT00
KHP201E454M432AT00
KHP201E684M432AT00
KHP201E105M432AT00
KHP201E155M552AT00
KHP201E225M552AT00
KHP201E335M762BT00
KHP201E475M762BT00
Rated voltage
(V
dc
)
Rated Capacitance
(mF)
33
47
68
100
150
200
15
20
33
47
68
100
4.5
6.8
10
15
22
33
47
1.5
2.0
3.0
4.7
6.8
10
15
0.45
0.68
1.0
1.5
2.2
3.3
4.7
Dimensions(mm)
L
4.8P0.4
6.0P0.4
7.8P0.5
4.8P0.4
6.0P0.4
7.8P0.5
4.8P0.4
6.0P0.4
7.8P0.5
4.8P0.4
W
3.5P0.4
5.0P0.4
6.6P0.5
3.5P0.3
5.0P0.4
6.6P0.5
3.5P0.3
5.0P0.4
6.6P0.5
3.5P0.3
Tmax.
5.5
5.0
5.6
6.5
5.5
4.5
5.6
6.5
5.5
4.5
5.6
6.5
5.5
4.5
5.6
6.5
5.5
4.5
5.6
6.5
1.5P0.3
1.3P0.3
a
1.3P0.3
1.3P0.3
1.5P0.3
1.3P0.3
1.3P0.3
1.5P0.3
1.3P0.3
1.3P0.3
Previous Part Number
(Just for your reference)
16
25
50
100
6.0P0.4
7.8P0.5
4.8P0.4
6.0P0.4
7.8P0.5
5.0P0.4
6.6P0.5
3.5P0.3
5.0P0.4
6.6P0.5
1.3P0.3
1.5P0.3
1.3P0.3
1.3P0.3
1.5P0.3
200
THP50E1C336MT002
THP50E1C476MT002
THP60E1C686MT002
THP60E1C107MT002
THP70E1C157MT002
THP70E1C207MT002
THP50E1E156MT002
THP50E1E206MT002
THP60E1E336MT002
THP60E1E476MT002
THP60E1E686MT002
THP70E1E107MT002
THP50E1H455MT002
THP50E1H685MT002
THP60E1H106MT002
THP60E1H156MT002
THP60E1H226MT002
THP70E1H336MT002
THP70E1H476MT002
THP50E2A155MT002
THP50E2A205MT002
THP50E2A305MT002
THP60E2A475MT002
THP60E2A685MT002
THP60E2A106MT002
THP70E2A156MT002
THP50E2D454MT002
THP50E2D684MT002
THP50E2D105MT002
THP60E2D155MT002
THP60E2D225MT002
THP70E2D335MT002
THP70E2D475MT002
(3/4)
CAT. No. E1002K
MULTILAYER CERAMIC CAPACITORS
METAL CAP TYPE MULTILAYER CERAMIC CAPACITORS
?PART
NUMBERING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
?DIMENSIONS
Spring mechanism
T
K MP 2 5 0 E 4 7 6 M 5 5 2 E T 0 0
Supplement code
Taping code
Terminal code
Size code
Capacitance tolerance code
Nominal Capacitance code
Temperature characteristics code
Rated voltage code
Series code
Category
L
?TMP
SERIES STANDARD RATINGS
Part Number
KMP250E336M552ET00
KMP250E476M552ET00
KMP250E686M762ET00
KMP250E107M762ET00
KMP500E106M552ET00
KMP500E156M552ET00
KMP500E226M552ET00
KMP500E336M762ET00
KMP500E476M762ET00
KMP101E475M552ET00
KMP101E685M552ET00
KMP101E106M762ET00
KMP101E156M762ET00
KMP201E155M552ET00
KMP201E225M552ET00
KMP201E335M762ET00
KMP201E475M762ET00
Rated voltage
(V
dc
)
Rated Capacitance
(mF)
33
47
68
100
10
15
22
33
47
4.7
6.8
10
15
1.5
2.2
3.3
4.7
Dimensions(mm)
L
6.4P0.4
8.2P0.5
6.4P0.4
8.2P0.5
6.4P0.4
8.2P0.5
6.4P0.4
8.2P0.5
W
5.0P0.4
6.6P0.5
5.0P0.4
6.6P0.5
5.0P0.4
6.6P0.5
5.0P0.4
6.6P0.5
Tmax.
5.0
6.5
5.0
6.5
5.0
6.5
5.0
6.5
a
1.3P0.3
1.5P0.3
1.3P0.3
1.5P0.3
1.3P0.3
1.5P0.3
1.3P0.3
1.5P0.3
Previous Part Number
(Just for your reference)
W
a
25
50
100
200
TMP60E1E336MT002
TMP60E1E476MT002
TMP70E1E686MT002
TMP70E1E107MT002
TMP60E1H106MT002
TMP60E1H156MT002
TMP60E1H226MT002
TMP70E1H336MT002
TMP70E1H476MT002
TMP60E2A475MT002
TMP60E2A685MT002
TMP70E2A106MT002
TMP70E2A156MT002
TMP60E2D155MT002
TMP60E2D225MT002
TMP70E2D335MT002
TMP70E2D475MT002
(4/4)
CAT. No. E1002K
