XO-543
Vishay Dale
Full Size Clock Oscillators TTL/HCMOS Compatible
FEATURES
•
•
•
•
•
•
•
•
•
Size: 14 pin full size
Industry standard
Wide frequency range
Low cost
Tri-state enable/disable
Resistance weld package
3.3 V
Compliant to RoHS Directive 2002/95/EC
Halogen-free according to IEC 61249-2-21 definition
The XO-543 series is with 3.3 V power supply. The metal
package with pin 7 case ground acts as shielding to
minimize EMI radiation.
STANDARD ELECTRICAL SPECIFICATIONS
PARAMETER
Frequency range
Frequency stability
(1)
Operating temperature range
Storage temperature range
Power supply voltage
Aging (first year)
Supply current
Output symmetry
Rise time
Fall time
Output voltage
Output load
Start-up time
Pin 1, tri-state function
SYMBOL
F
O
T
OPR
T
STG
V
DD
CONDITION
-
all conditions
-
-
-
25 °C ± 3 °C
1.000 MHz to 23.999 MHz
24.000 MHz to 49.999 MHz
50.000 MHz to 69.999 MHz
70.000 MHz to 100.000 MHz
at ½ V
DD
10 % V
DD
to 90 % V
DD
90 % V
DD
to 10 % V
DD
-
-
-
-
-
-
-
VALUE
1.000 MHz to 100.000 MHz
± 25 ppm, ± 50 ppm, ± 100 ppm
0 ºC to 70 ºC
- 40 ºC to + 85 ºC (option)
- 55 ºC to + 125 ºC
3.3 V ± 10 %
± 5 ppm
15 mA max.
20 mA max.
30 mA max.
45 mA max.
40 %/60 % (45 %/55 % option)
8 ns max.
8 ns max.
90 % V
DD
min.
10 % V
DD
max.
1 TTL to 5 TTL
to 50M: 30 pF
to 125M: 15 pF
10 ms max.
pin 1 = H or open (output active at pin 3)
pin 1 = L (high impedance at pin 3)
I
DD
Sym
t
r
t
f
V
OH
V
OL
TTL load
HCMOS load
t
s
Note
(1)
Include: 25 ºC tolerance, operating temperature range, input voltage change, aging, load change, shock and vibration
DIMENSIONS
in inches [millimeters]
CMOS
LOAD
CL
(1)
max.
Note
(1)
Includes Stray and Probe Capacitance
max.
OH
DD
max.
IH
≥
DC
OL
DD
DD
max.
DD
Document Number: 35038
Revision: 08-Mar-11
For technical questions, contact:
frequency@vishay.com
www.vishay.com
25
