240-381J
MIL-DTL-38999 Series I Type Filter Connector
Jam Nut Receptacle
TABLE II: CAPACITOR ARRAY CODE
CAPACITANCE RANGE
H
CLASS
X*
Y*
J
PI - CIRCUIT (pF)
160,000 - 240,000
80,000 - 120,000
60,000 - 90,000
38,000 - 56,000
32,000 - 45,000
18,000 - 33,000
8,000 - 12,000
3,300 - 5,000
800 - 1,300
400 - 600
C - CIRCUIT (pF)
80,000 - 120,000
40,000 - 60,000
30,000 - 45,000
19,000 - 28,000
16,000 - 22,500
9,000 - 16,500
4,000 - 6,000
1,650 - 2,500
400 - 650
200 - 300
B
C
D
E
F
G
H
J
11
13
15
17
19
21
23
25
SHELL
SIZE
CODE
A
Z*
A
B
MIL-DTL-38999 Series I
Jam Nut Panel Cutout
SHELL
SIZE
09
H
.710 (18.0)
.700 (17.8)
.835 (21.2)
.825 (21.0)
1.020 (25.9)
1.010 (25.7)
1.145 (29.1)
1.135 (28.8)
1.270 (32.3)
1.260 (32.0)
1.395 (35.4)
1.385 (35.2)
1.520 (38.6)
1.510 (38.4)
1.645 (41.8)
1.635 (41.5)
1.770 (45.0)
1.760 (44.7)
J
.670 (17.0)
.660 (16.8)
.771 (19.6)
.761 (19.3)
.955 (24.3)
.945 (24.0)
1.085 (27.6)
1.075 (27.3)
1.210 (30.7)
1.200 (30.5)
1.335 (33.9)
1.325 (33.7)
1.460 (37.1)
1.450 (36.8)
1.585 (40.3)
1.575 (40.0)
1.710 (43.4)
1.700 (43.2)
Recomended
Panel Cut-Out
C
D
E
F
G
* Reduced DWV – Please consult factory.
TABLE I: CONNECTOR CLASS
SYM
M
MT
NF
P
ZN
CLASS
Environmental
Environmental
Environmental
Environmental
Environmental
MATERIAL
Aluminum
Aluminum
Aluminum
Stainless
Steel
Aluminum
FINISH DESCRIPTION
Electroless Nickel
Ni-PTFE
1000 Hour Grey
Nickel Fluorocarbon Polymer
TM
Cadmium O.D. Over Electroless
Nickel
Electro-Deposited Nickel
Zinc-Nickel Over Electroless Nickel
DIMENSIONS
SHELL
SIZE
9
11
13
15
17
19
21
23
25
A
.855 (21.7)
.645 (16.4)
.755 (19.2)
.745 (18.9)
.942 (23.9)
.932 (23.7)
1.066 (27.1)
1.056 (26.8)
1.191 (30.3)
1.181 (30.0)
1.316 (33.4)
1.306 (33.2)
1.441 (36.6)
1.431 (36.3)
1.566 (39.8)
1.556 (39.5)
1.691 (43.0)
1.681 (42.7)
B
1.078 (27.4)
1.046 (26.6)
1.266 (32.2)
1.234 (31.3)
1.391 (35.3)
1.359 (34.5)
1.516 (38.5)
1.484 (37.7)
1.641 (41.7)
1.609 (40.9)
1.828 (46.4)
1.796 (45.6)
1.954 (49.6)
1.922 (48.8)
2.078 (52.8)
2.046 (52.0)
2.204 (56.0)
2.172 (55.2)
C THREAD
CLASS 2A
UNEF PLATED
.6875-24
.8125-20
1.0000-20
1.1250-18
1.2500-18
1.3750-18
1.5000-18
1.6250-18
1.7500-18
D THREAD
CLASS 2A
UNEF PLATED
.4375-28
.5625-24
.8875-24
.8125-20
.9375-20
1.0625-18
1.1875-18
1.3125-18
1.4375-18
E
DIA
1.188 (30.2)
1.375 (34.9)
1.500 (38.1)
1.625 (41.3)
1.750 (44.5)
1.938 (49.2)
2.062 (52.4)
2.188 (55.6)
2.312 (58.7)
F
.670 (17.0)
.661 (16.8)
.771 (19.6)
.762 (19.4)
.955 (24.3)
.946 (24.0)
1.085 (27.6)
1.076 (27.3)
1.210 (30.7)
1.201 (30.5)
1.335 (33.9)
1.326 (33.7)
1.460 (37.1)
1.451 (36.9)
1.585 (40.3)
1.578 (40.1)
1.710 (43.4)
1.701 (43.2)
G
DIA
.709 (18.0)
.700 (17.8)
.834 (21.2)
.825 (21.0)
1.019 (25.9)
1.010 (25.7)
1.144 (29.1)
1.135 (28.8)
1.269 (32.2)
1.260 (32.0)
1.394 (35.4)
1.385 (35.2)
1.519 (38.6)
1.510 (38.4)
1.644 (41.8)
1.635 (41.5)
1.769 (44.9)
1.760 (44.7)
H
.120 (3.0)
.100 (2.5)
.120 (3.0)
.100 (2.5)
.120 (3.0)
.100 (2.5)
.120 (3.0)
.100 (2.5)
.120 (3.0)
.100 (2.5)
.151 (3.8)
.130 (3.3)
.151 (3.8)
.130 (3.3)
.151 (3.8)
.130 (3.3)
.151 (3.8)
.130 (3.3)
© 2008 Glenair, Inc.
www.glenair.com
CAGE CODE 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
B-9
MIL-DTL-38999
