RL101GP
THRU
RL107GP
1.0 Amp Standard
Recovery Rectifier
Features
l
Plastic package has Underwriters Laboratory
Flammability Classification 94V-0 utilizing
Flame Retardant Epoxy Molding Compound
l
l
Glass passivated junction version of RL101G thru RL107G
1.0 Ampere operation at T
A
=75 C with no thermal runaway
o
50-1000 Volts
A-405
Maximum Ratings
l
l
l
Operating Temperature: -55 C to +150 C
Storage Temperature: -55 C to +150 C
Maximum Thermal Resistance; 50 C/W Junction To Lead
Maximum
Maximum
Recurrent M a x i m u m
DC
Peak
RMS
Blocking
Reverse
Voltage
Voltage
Voltage
50V
35V
50V
100V
70V
100V
200V
140V
200V
400V
280V
400V
600V
420V
600V
800V
560V
800V
1000V
700V
1000V
o
o
o
o
o
MCC
Catalog
Number
RL101GP
RL102GP
RL103GP
RL104GP
RL105GP
RL106GP
RL107GP
Device
Marking
---
---
---
---
---
---
---
D
A
Cathode
Mark
B
D
Electrical Characteristics @ 25
o
C Unless Otherwise Specified
Average Forward
Current
Peak Forward
Surge Current
Maximum
Instantaneous
Forward Voltage
Maximum DC
Reverse Current
At Rated DC
Blocking Voltage
Typical Junction
Capacitance
I
F(AV)
I
FSM
V
F
1.0A
30A
1.10V
T
A
=75
o
C
8.3mS Sina Half
I
F
=1.0A;T
A
=25
o
C
C
DIMENSIONS
INCHES
DIM
MM
NOTE
MIN
A
B
C
D
0.166
0.080
-----
1.000
MAX
0.205
0.107
0.024
-----
MIN
4.10
2.00
-----
25.40
MAX
5.20
2.70
0.60
-----
I
R
5.0uA
50uA
15pF
T
A
=25 C
T
A
=125
o
C
Measured at
1.0MHz;V
R
=4.0V
o
C
J
*Pulse test: Pulse width 300 sec, Duty cycle 2%
