L-955XX-TR
3.6x2.8x1.9mm SMD LED (TOP LED)
◆
PACKAGE DIMENSIONS
2.8(.110)
2.2(.087)
G
SG
Y
E
VE UY
1.9(.075)
0.8(.031)
2.4(.094)
3.6(.142)
3.2(.126)
0.9(.035)
SR
UR
0.8(.031)
Cathode
(Aonde for SRC, URC)
0.14(.005) 0.6(.024)
Cathode Mark
1.50±0.10
Processive Direction
1.75±0.10
3.50±0.05
4.0
2.24±0.10
4.00±0.10
4.00±0.10
Loaded quantity per reel：2000 pcs/reel
：
8.00±0.20
View
Angle
(deg)
120
120
120
120
120
120
120
120
Chip
Part No.
L-955GC-TR
L-955SGC-TR
L-955YC-TR
L-955EC-TR
L-955SRC-TR
L-955URC-TR
L-955VEC-TR
L-955UYC-TR
Raw
Material
GaP
GaP
GaAsP/GaP
GaAsP/GaP
GaAlAs
GaAlAs
GaAlInP
GaAlInP
Emitted
Color
Green
Super Green
Yellow
Hi.effi Red
Super Red
Super Red
Super Orange
Super Yellow
Lens Color
Water Clear
Water Clear
Water Clear
Water Clear
Water Clear
Water Clear
Water Clear
Water Clear
Wave
Length
λ
p(nm)
565
565
585
635
660
660
625
592
Electro-Optical Characteristics
Vf(V)20mA
Iv(mcd)10mA
Typ.
Max.
Typ.
2.1
2.6
20
2.1
2.6
30
2.1
3.0
17
2.1
3.0
23
1.7
2.2
140
1.7
2.2
280
2.0
2.4
300
2.0
2.4
280
1.All dimension are in millimeters (inches).
2.Tolerance is
±0.25
mm (0.01”) unless otherwise specified.
