MURF1020CT
MURF1020CT ULTRAFAST PLASTIC RECTIFIER
Features:
•
•
•
•
•
Utra-Fast Switching
High Current Capability
Low Reverse Leakage Current
High Surge Current Capability
Plastic Material has UL Flammability Classification 94V-O
Mechanical Data:
•
•
•
•
•
Case: Molded Plastic
Terminals: Plated Leads, Solderable per MIL-STD-202, Method 208
Weight: 2.24 grams (approx.)
Marking: Type Number
Mounting Position: Any
Mechanical Dimensions: In mm / Inches
ITO-220AB
•
221 West Industry Court
Deer Park, NY 11729-4681
(631) 586-7600 FAX (631) 242-9798
•
•
World Wide Web Site - http://www.sensitron.com
•
E-Mail Address - sales@sensitron.com
•
SENSITRON
SEMICONDUCTOR
Data Sheet 2678, Rev. A
MURF1020CT
Maximum Ratings:
Characteristics
Peak Inverse Voltage
Max. Average Forward
Max. Peak One Cycle Non-
Repetitive Surge Current
(Per leg)
Symbol
V
RWM
I
F (AV)
Condition
-
50% duty cycle @Tc=100°C,
rectangular wave form
8.3ms, Half Sine pulse
Max.
200
10
Units
V
A
I
FSM
100
A
Electrical Characteristics:
Characteristics
Max. Forward Voltage Drop*
Symbol
V
F1
V
F2
I
R1
Max. Reverse Current*
I
R2
Max.ReverseRecoveryTime
RSM Isolation Voltage
(t=1.0 second,R.H.<
=30%,
T
A
=25°C)
t
rr
V
1so
Condition
@ 10A, Pulse, T
J
= 25°C
@ 10A, Pulse, T
J
= 100°C
@V
R
= rated V
R
T
J
= 25°C
@V
R
= 0.8 V
R
T
J
= 100°C
I
F
=500mA, I
R
=1A,and I
rm
=250mA
Clip mouting, the epoxy body
away from the heatsink edge by
more than 0.110”along the lead
direction.
Clip mouting, the epoxy body is
inside the heatsink
Screw mounting, the epoxy body
is inside the heatsink
Max.
1.2
1.0
10
100
35
4500
Units
V
V
µA
µA
ns
V
3500
1500
* Pulse width < 300 µs, duty cycle < 2%
Thermal-Mechanical Specifications:
Characteristics
Max. Junction Temperature
Max. Storage Temperature
Maximum Thermal
Resistance Junction to Case
Approximate Weight
Mounting Torque
Case Style
Symbol
T
J
T
stg
R
θJC
wt
T
M
Condition
-
-
DC operation
-
Specification
-55 to +150
-55 to +150
5.0
2.24
6(Min.)
12(Max.)
ITO-220AB
Units
°C
°C
°C/W
g
Kg-cm
•
