AC-DC Switching Power Supply
AQS75U SERIES
KEY FEATURES
U Bracket Switching Power Supply
Universal Input: 90-264 VAC
Single Output
5 VDC to 24 VDC Output
3000 VAC Input to Output Isolation
Ultra Compact Size: 4.15 x 2.3 x 1.5 Inches
2-Years Product Warranty
75 Watts
ELECTRICAL SPECIFICATIONS
Model No.
Max Output Wattage (W)
Voltage
Frequency (Hz)
Input
Current (Full load)
Inrush Current (<2ms)
Leakage Current
Voltage (V.DC.)
Voltage Accuracy
Current (mA) max
Line Regulation (LL-HL) (typ.)
Load Regulation (5-100%) (typ.)
Output
Minimum Load
Maximum Capacitive Load
Ripple & Noise (Vp-p)
Efficiency
Hold-up Time
Switching Frequency
Over Power Protection
Protection
Over Voltage Protection
Short Circuit Protection
Input-Output (V.AC)
Isolation
Input-FG
Output-FG
(V.AC)
.(V.AC)
AQS75U-5S
60W
47-63 Hz
2 A max. (115 VAC) / 1 A max. (230 VAC)
20 A max. (115 VAC) / 40 A max. (230 VAC)
3.5 mA max.
5V
±2%
12,000
±1%
±1%
1%
470-23,000µF depending on model
100 mV
73%
18 ms min.
133 kHz
Auto recovery
Zener diode clamp
Auto recovery
3000V
1500V
500V
-25°C…+70°C (with derating)
-40°C…+85°C
±0.02%/°C
95% RH
>130,000 h @ 25°C (MIL-HDBK-217F)
10~500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes.
4.15 x 2.3 x 1.5 Inches
285 g
Free air convection
CE, UL
EN 55022 class B
EN 55024
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Measured with 0.1μ 50V // 47μ 50V Ceramic Cap. Cross to output
AQS75U-12S
75W
AQS75U-15S
75W
AQS75U-24S
75W
90-264 VAC or 120-370 VDC
12V
6,250
15V
5,000
24V
3,130
max.
150 mV
80%
max.
200 mV
80%
max.
300 mV
80%
max.
Operating Temperature
Storage Temperature
Environment
Temperature Coefficient
Humidity
MTBF
Vibration
Dimension (L x W x H)
Physical
Safety
EMC
Weight
Cooling Method
Agency Approvals
EMI
(Conducted & Radiated Emission)
EMS
(Noise Immunity)
( 105.3 x 58.2 x 38.1 mm ) Tolerance
±0.5
mm
http://www.archcorp.com.tw
TEL: +886-2-26989508 FAX: +886-2-26981319
