SMD Power Inductors - Molded
ctparts.com
CTP1330F Series
From 1.0 µH to 1,000 µH
Part
Number
CTP1330F-102K
CTP1330F-122K
CTP1330F-152K
CTP1330F-182K
CTP1330F-222K
CTP1330F-272K
CTP1330F-332K
CTP1330F-392K
CTP1330F-472K
CTP1330F-562K
CTP1330F-682K
CTP1330F-822K
CTP1330F-103K
CTP1330F-123K
CTP1330F-153K
CTP1330F-183K
CTP1330F-223K
CTP1330F-273K
CTP1330F-333K
CTP1330F-393K
CTP1330F-473K
CTP1330F-563K
CTP1330F-683K
CTP1330F-823K
Not shown at actual size.
SPECIFICATIONS
Part numbers indicate tolerance available.
K = ±10%
Inductance
(µH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000.0
Test
Freq.
(KHz)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
DCR
Max.
Ω
(Ω)
0.035
0.041
0.043
0.048
0.075
0.080
0.108
0.118
0.125
0.145
0.165
0.180
0.216
0.252
0.288
0.328
0.384
0.425
0.538
0.600
0.792
0.900
1.020
1.380
1.680
1.800
2.040
2.400
2.648
4.320
4.800
5.640
6.000
6.960
8.760
9.960
11.160
Incremental DC Rated DC
Current.
Current
(mA)
(mA)
1526
1400
1291
1180
1104
936
840
732
720
612
600
600
564
516
432
420
348
324
270
270
246
216
174
150
132
111
106
89
72
60
57
48
41
35
30
26
22
2780
2690
2030
1950
1960
1550
1460
1390
1330
1110
1080
1020
946
912
858
817
694
657
568
488
467
442
384
362
347
327
272
261
223
191
179
171
161
138
130
113
105
Compliant
RoHS
CHARACTERISTICS
Description:
SMD Molded High Current Inductors
Applications:
Excellent power line noise filters, filters for
switching regulated power supplies, DC/DC converters, SCR and
Triac controls and RFI suppression.
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±10%
Incremental Current:
The current at which the inductance will be
decreased by a maximum of 5% from its initial zero DC value
Testing:
Tested on a HP4284A at 1KHz
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant.
Marking:
Parts are marked with inductance code
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
CTP1330F-104K
CTP1330F-124K
CTP1330F-154K
CTP1330F-184K
CTP1330F-224K
CTP1330F-274K
CTP1330F-334K
CTP1330F-394K
CTP1330F-474K
CTP1330F-564K
CTP1330F-684K
CTP1330F-824K
CTP1330F-105K
PHYSICAL DIMENSIONS
Size
mm
inches
A
7.6~8.2
0.300~0.326
B
2.7~3.8
0.110~0.150
C
3.1~3.6
0.125~0.145
D
1.9±0.25
0.075±0.010
E
1.0~2.0
0.040~0.080
A
E
C
D
D
B
11.28.06
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
