Three Phase Filters
Residential / Light industrial environments
High performance, footprint design
Offered as the three phase counterpart to the F.LL.E2. - A.FP type single
phase series, these filters boast the same compact dimensions twinned
with high performance. Suppression components are mounted on a printed
circuit board in a vented aluminium enclosure.
F.LL.D3
series –
FP
type
•
Current ratings from 8A to 17A
•
High attenuation performance
•
Space saving, lightweight, footprint or stand alone mounting
Mechanical specifications
Manufacture:
Connections:
aluminium enclosure with ventilation slots.
internal components printed circuit board mounted.
phases: terminal blocks to accept 16mm
2
wire.
earth: M4 threaded terminal.
Circuit diagram
Electrical specifications
Rated voltage (V
R
):
Rated current (I
R
):
Leakage current (I
L
):
Voltage test (2
S
):
Climatic category:
480Vac 50/60Hz
referred to room temperature = 40°C
at V
R
/
√3,
50Hz, max value
lines to ground 2700Vdc
line to line 1700Vdc
HPF (25/085/21);
temperature range: -25°C to +85°C
Dimensions (mm) and connections
Filter range
Code
I
R
I
L
(mA)
78.3
78.3
78.3
Cx
(µF)
9x1
9x1
3x1.5 + 6x1
Cy
(µF)
2 x 0.47
2 x 0.47
2 x 0.47
L
(mH)
6x4.5 + 3x0.036
6x4.5 + 3x0.036
6x4.5 + 3x0.036
R
(MΩ)
3 x0.47
3 x0.47
3 x0.47
(A)
F.LL.D3.008A.FP.01 8
F.LL.D3.015A.FP.01 15*
F.LL.D3.017A.FP.01 17*
* with 2° C/W HSK
= See leakage current
note on page two
Dimensions
Code
A B C
F.LL.D3.008A.FP.01 177.5 185 158
F.LL.D3.015A.FP.01 177.5 185 158
F.LL.D3.017A.FP.01 177.5 185 158
D
138
138
138
E
207
207
207
F
188
188
188
G
5
5
5
H J K
10 6.5 5
10 6.5 5
10 6.5 5
L
46
46
46
M
22.5
22.5
22.5
N O
200 22.5
200 22.5
200 22.5
Insertion loss
(Typical)
– – – Symmetrical (line to line) –––– Asymmetrical (line to ground)
...F.LL.D3.008A...
...F.LL.D3.015A...
...F.LL.D3.017A...
Approvals
Made in accordance to VDE, UL and CSA requirements
19
Load
Line
