P300A thru P300M
General Purpose Plastic Rectifiers
Reverse Voltage 50 to 1000 Volts Forward Current 3.0 Amperes
Features
Plastic package has Underwriters Laboratories Flammability
Classification 94V-0
High surge current capability
Typical I
R
less than 0.1uA
Construction utilizes void-free molded plastic technique
3.0 Amperes operation at T
A
=90
o
C with no thermal runaway
High temperature soldering guaranteed:
250
o
C/10 seconds, 0.375" (9.5mm) lead length,
5 lbs. (2.3kg) tension
T
J
is 150
o
C (Max.) and T
STG
is 175
o
C (Max.) with PI glue
Mechanical Data
Case: JEDEC DO-201AD, molded plastic body
Terminals: Plated axial leads, solderable per MIL-STD-750,
Method 2026
Polarity: Color band denotes cathode end
Mounting Position: Any
Weight: 0.04 ounce, 1.1 grams
Maximum Ratings and Electrical Characteristics
Ratings at 25
o
C ambient temperature unless otherwise specified.
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375" (9.5mm) lead length at T
A
=55
o
C
Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method)
Maximum instantaneous forward voltage at 3.0A
Maximum DC reverse current
at rated DC blocking voltage
Typical reverse recovery time at
I
F
=0.5A, I
R
=1.0A, I
rr
=0.25A
Typical junction capacitance at 4.0V, 1MHz
Typical thermal resistance (Note 1)
Operating junction temperature range
Storage temperature range
T
A
=25 C
T
A
=100
o
C
o
Symbols
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
t
rr
C
J
R
θ
JA
R
θ
JL
T
J
T
STG
P 300A
50
35
50
P 300B
100
70
100
P 300D
200
140
200
P 300G
400
280
400
3.0
P 300J
600
420
600
P 300K
800
560
800
P 300M
1000
700
1000
Units
Volts
Volts
Volts
Amps
200.0
1.2
5.0
25
1.0
30
20.0
5.0
-55 to +125
-55 to +150
Amps
Volts
uA
us
pF
o
C/W
o
C
C
o
Notes:
1. Thermal resistance from junction to ambient and from junction to lead at 0.375" (9.5mm) lead length, P.C.B. mounted with 0.8" x 0.8" (20 x 20mm)
copper heatsinks
