Intel
®
Celeron
®
Processor
up to 1.10 GHz
Datasheet
s
s
s
s
s
s
s
Available at 1.10 GHz, 1 GHz, 950 MHz,
900 MHz, 850 MHz, 800 MHz, 766 MHz,
733 MHz, 700 MHz, 667 MHz, 633 MHz,
600 MHz, 566 MHz, 533 MHz,
533A MHz, 500 MHz, 466 MHz,
433 MHz, 400 MHz, 366 MHz, 333 MHz,
and 300A MHz core frequencies with
128 KB level-two cache (on die); 300 MHz
and 266 MHz core frequencies without
level-two cache.
Intel’s latest Celeron
®
processors in the
FC-PGA/FC-PGA2 package are
manufactured using the advanced 0.18
micron technology.
Binary compatible with applications
running on previous members of the Intel
microprocessor line.
Dynamic execution microarchitecture.
Operates on a 100/66 MHz, transaction-
oriented system bus.
Specifically designed for uni-processor
based Value PC systems, with the
capabilities of MMX™ technology.
Power Management capabilities.
s
s
s
s
Optimized for 32-bit applications running
on advanced 32-bit operating systems.
Uses cost-effective packaging technology.
— Single Edge Processor (S.E.P.) Package
to maintain compatibility with SC242
(processor core frequencies (MHz):
266, 300, 300A, 333, 366, 400, 433).
— Plastic Pin Grid Array (PPGA) Package
(processor core frequencies (MHz):
300A, 333, 366, 400, 433, 466, 500,
533).
— Flip-Chip Pin Grid Array (FC-PGA /
FC-PGA2) Package (processor core
frequencies (MHz); 533A, 566, 600,
633, 667, 700, 733, 766, 800, 850, 900,
950); (GHz); 1, 1.10
Integrated high-performance 32 KB
instruction and data, nonblocking, level-
one cache: separate 16 KB instruction and
16 KB data caches.
Integrated thermal diode.
The Intel
®
Celeron
®
processor is designed for uni-processor based Value PC desktops and is
binary compatible with previous generation Intel architecture processors. The Celeron processor
provides good performance for applications running on advanced operating systems such as
Microsoft* Windows*98, Windows NT*, Windows* 2000, Windows XP* and Linux*. This is
achieved by integrating the best attributes of Intel processors—the dynamic execution
performance of the P6 microarchitecture plus the capabilities of MMX™ technology—bringing
a balanced level of performance to the Value PC market segment. The Celeron processor offers
the dependability you would expect from Intel at an exceptional value. Systems based on
Celeron processors also include the latest features to simplify system management and lower the
cost of ownership for small business and home environments.
FC-PGA2 Package
