NACZ151M6.3V6.3X6.3TR13 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> NACZ151M6.3V6.3X6.3TR13

NACZ151M6.3V6.3X6.3TR13: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 6.3V, 20% +Tol, 20% -Tol, 150uF, Surface Mount, 2626, CAN; CategoryPassive components capacitor; File Size139KB，2 Pages; ManufacturerNichicon; Websitehttp://www.nichicon.co.jp

Download Datasheet Parametric View All

NACZ151M6.3V6.3X6.3TR13 Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 6.3V, 20% +Tol, 20% -Tol, 150uF, Surface Mount, 2626, CAN

NACZ151M6.3V6.3X6.3TR13 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Nichicon
package instruction	CAN
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	150 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)
high	6.3 mm
JESD-609 code	e0
leakage current	0.00945 mA
length	7.2 mm
Manufacturer's serial number	NACZ
Installation features	SURFACE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package shape	CYLINDRICAL PACKAGE
Package form	SMT
method of packing	TR, 13 INCH
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	6.3 V
ripple current	230 mA
series	NACZ
size code	2626
surface mount	YES
Delta tangent	0.24
Terminal surface	Tin/Lead (Sn/Pb)
Terminal shape	FLAT
width	6.6 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Surface Mount Aluminum Electrolytic Capacitors

FEATURES

•

CYLINDRICAL LEADLESS TYPE FOR SURFACE MOUNTING

VERY LOW IMPEDANCE & HIGH RIPPLE CURRENT AT 100K Hz

SUITABLE FOR DC-DC CONVERTER, DC-AC INVERTER, ETC.

NEW EXPANDED CV RANGE, UP TO 3300µF

*See Part Number System for Details

ANTI-SOLVENT (2 MINUTES)

DESIGNED FOR AUTOMATIC MOUNTING AND REFLOW SOLDERING

Rated Voltage Range

Rated Capacitance Range

Operating Temp. Range

Capacitance Tolerance

Max. Leakage Current

After 2 Minutes @ 20

6.3 ~ 50 Vdc

4.7 ~ 3300

µF

-55 ~ +105

±20%(M), ±10%(K)*

0.01CV or 3

A, whichever is

greater

W.V. (Vdc)

6.3

S.V. (Vdc)

8.0

4 ~ 6mm Dia.

0.24 0.20 0.16 0.14 0.12 0.10

C < 1000

µF

0.28 0.24 0.20 0.16 0.14 0.12

C =1500

µF

0.29 0.25 0.21

8mm Dia ~ up

C =2200

µF

0.30 0.26

C =3300

µF

0.32

W.V. (Vdc)

6.3

Z-40

C/Z +20

Z-55 C/Z +20 C

Capacitance Change

Within ±25% of initial measured value

Tan

Less than 200% of specified max. value

Leakage Current

Less than specified max. value

NACZ Series

RoHS

Compliant

CHARACTERISTICS

Tan

@ 120Hz/20

LOW IMPEDANCE

AT HIGH FREQUENCY.

INDUSTRY STANDARD

STYLE FOR SWITCHERS

AND CONVERTERS

LOW ESR COMPONENT

LIQUID ELECTROLYTE

For Performance Data

see www.LowESR.com

Low Temperature

Stability

Impedance Ratio @ 120Hz

Load LifeTest @ 105°C

4~6mm Dia 1,000 Hours

8~12.5mm Dia 2,000 Hours

* Optional ± 10% (K) Tolerance available on most values. Contact factory for availability.

MAXIMUM PERMISSIBLE RIPPLE CURRENT

(mA rms AT 100KHz AND 105

Cap (µF)

4.7

100

120

150

220

330

470

680

1000

1500

2200

3300

Working Voltage (Vdc)

6.3

150

230

280

450

670

900

150

230

280

450

670

900

150

230

280

450

670

900

150

230

280

450

670

900

150

230

280

450

670

900

165

185

300

670

620

790

MAXIMUM IMPEDANCE

(Ω AT 20

C AND 100KHz)

Cap (µF)

4.7

100

120

150

220

330

470

680

1000

1500

2200

3300

Working Voltage (Vdc)

6.3

1.80

0.76

0.44

0.34

0.17

0.09

0.066

1.80

1.80 0.76

1.80

0.76

0.44

0.76

0.44 0.44

0.44

0.34

0.44

0.34 0.34

0.34

0.17 0.17

0.17

0.17 0.17

0.17

0.09

0.17

0.09

0.066

1.80

0.76 0.88

0.76

0.76 0.88

0.44 0.75

0.34 0.40

0.40

0.17 0.22

0.09 0.14

0.078

0.066
